Grizzly H0589 Instruction Sheet

EyE/EAR INJURy HAzARD!
Wear safety glasses and
hearing protection during
use of this tool!
Always disconnect tool from
air to prevent unexpected
operation during service!
Never exceed 90 pSI! Always
use accessories with correct
speed rating.
RESpIRATORy HAzARD!
Grinding
dust. Wear the appropriate
protection during use!

Introduction

No load speed is 20,000 RPM and collet size is
⁄ ". Requires maximum of 90 PSI with a minimum
1
4
of 4 CFM compressor capacity. Air inlet is
air exhaust is in the rear. Weighs 1.2 lbs.

Inventory

A. Die Grinder ................................................. 1
B. Wrenches ................................................... 2

Operation

Insert your ⁄ " shank tool into the collet. Using the
1
4
two wrenches, secure tool by tightening the collet
nut against the spindle.
CoPyRIGHt © FebRUARy, 2006 by GRIzzLy INDUStRIAL, INC. RevISeD SePteMbeR, 2009 (bL)
WARNING: NO pORTION OF THIS MANUAL MAy BE REpRODUCED IN ANy SHApE
OR FORM WITHOUT THE WRITTEN AppROvAL OF GRIzzLy INDUSTRIAL, INC.
INJURy HAzARD!
EXpLOSION HAzARD!
produces
#PC8027 PRINteD IN tAIWAN
⁄
1
4
fine
Die Grinder MUSt have 3-4 drops of oil directly
dropped into the air fitting before each use as
shown in Figure 2.
⁄ " and
1
4
Figure 2. Lubricating directly into air fitting.
If you need help with your new pneumatic tool,
call our Tech Support at: (570) 546-9663.
MODEL H0589
" AIR DIE GRINDER
INSTRUCTION SHEET
Figure 1. Model H0589.
