- Page 1 9.6V MINI GRINDER KIT WITH FLEX SHAFT INSTRUCTION MANUAL COPYRIGHT © DECEMBER, 2006 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. #TS8720 PRINTED IN CHINA...
- Page 2 ���� ������ �������� �������� ������ ������������ �� ��� ������ ������ ���������� ����������� ��� ������� �� ���� ������������������ ������� �� ����� ���������� ��� ������ ��� ������������ ����� �� ���� ������ ��� ������ �� ������� �������� ������� ��������� ����������� ������������� �� ������ ���...
-
Page 3: Table Of Contents
Table of Contents SECTION 1: SAFETY...2 Safety Instructions for Machinery ...2 Additional Safety Instructions for Mini Grinder ...4 Additional Safety Instructions for ...5 Batteries and Chargers ...5 SECTION 2: INTRODUCTION ...6 Foreword ...6 Contact Information ...6 SECTION 3: SET UP...7 Unpacking ...7... -
Page 4: Section 1: Safety
NIOSH 6. NEVER OPERATE MACHINERY WHEN TIRED, OR UNDER THE INFLUENCE ALCOHOL. Be mentally alert at all times when running machinery. HEARING DRUGS Model H8125 9.6V Mini Grinder Kit... - Page 5 Keep blades sharp and clean for best and safest performance. Follow instructions for lubricating and chang- ing accessories. Model H8125 9.6V Mini Grinder Kit 16. REMOVE ADJUSTING KEYS AND WRENCHES. Make a habit of check- ing for keys and adjusting wrenches before turning machinery ON.
-
Page 6: Additional Safety Instructions For Mini Grinder
Use this mini grinder and other machinery with caution and respect. Failure to do so could result in serious personal inju- ry, damage to equipment, or poor work results. Model H8125 9.6V Mini Grinder Kit... -
Page 7: Additional Safety Instructions For
DO NOT carry the charger by the cord, or yank the cord to unplug the charger. Model H8125 9.6V Mini Grinder Kit 5. CHARGER DAMAGE. Replace char- Only ger if it has been dropped, damaged, or received a hard impact. -
Page 8: Section 2: Introduction
Foreword We are proud to offer the Grizzly Model H8125 9.6V Mini Grinder Kit. This model is part of a growing Grizzly family of fine power tools. When used according to the guidelines set forth in this manual, you can expect years of trouble-free, enjoyable operation and proof of Grizzly’s commit-... -
Page 9: Section 3: Set Up
SECTION 3: SET UP Your Model H8125 was carefully packed when it left our warehouse. If you discover the Model H8125 is damaged after you have signed for delivery, please call Customer Service immediately at (570) 546-9663 for advice. Save the containers and all packing materials for possible inspection by the carrier or its agent. -
Page 10: Inventory
The setup and operation instructions will be easier to understand if you first become famil- iar with the components of the Model H8125 9.6V Mini Grinder Kit. Match the letters in Figure 1 with the inventory list below to identify each of the components that were shipped with your Model H8125. -
Page 11: Section 4: Operations
DC adapter. 3. Press the two side tabs on the battery and slide the battery from the grinder. Model H8125 9.6V Mini Grinder Kit 4. Position the flat part of the battery bot- tom to the front of the charger, align... -
Page 12: Using The Led Light Attachment
Figure 2. LED light attachment installed. 4. Use the small switch on the underside of the light attachment to switch the LED's ON and OFF. Installing Bits The Model H8125 uses bits and cutters with a ⁄ " or a ⁄... -
Page 13: Using The Grinder
Using the Grinder Most operations performed with the Model H8125 will give the best results at higher speeds. However, slower speeds are ideal when working with plastics or other materi- als that melt easily. -
Page 14: Installing The Flex Shaft
Hold the working end of the flex shaft FIRMLY before turning the grinder ON. ⁄ " of the desired bit into ⁄ " or the ⁄ " collet. ⁄ Flex Shaft Tool Model H8125 9.6V Mini Grinder Kit turn. -
Page 15: Section 5: Maintenance
3. Re-install the inner spindle into the flex shaft. Model H8125 9.6V Mini Grinder Kit Changing LED Light Attachment Batteries 1. With the light attachment removed from the grinder, unscrew the three Phillips head screws from the rim of the device. -
Page 16: Parts Breakdown
BATTERY CR-927 3VDC LED ASSEMBLY COVER ADAPTER 120VAC-12VDC BATTERY CHARGER 9.6V BATTERY NI-CD 9.6V ACCESSORY KIT FLEX SHAFT FLEX SHAFT INNER SPINDLE FLEX SHAFT COLLET NUT FLEX SHAFT TOOL Model H8125 9.6V Mini Grinder Kit � � � � � �... -
Page 17: Warranty And Returns
WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance. - Page 19 ____20-29 ____50-59 How long have you been a woodworker/metalworker? ____0-2 Years How many of your machines or tools are Grizzly? ____0-2 Do you think your machine represents a good value? ____Yes Would you recommend Grizzly Industrial to a friend? ____Yes Would you allow us to use your name as a reference for our customers in your area? Note: We never use names more than 3 times.
- Page 20 Send a Grizzly Catalog to a friend: Name________________________________ Street________________________________ City______________State______Zip_______ FOLD ALONG DOTTED LINE GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 TAPE ALONG EDGES--PLEASE DO NOT STAPLE Place Stamp Here...
