DA6 YUV A
SIX OUTPUT, HDTV/COMPONENT AND DIGITAL
AUDIO DISTRIBUTION AMPLIFIER
The Extron DA 6 YUV A distribution amplifier splits a signal from a single
HDTV/component video source and distributes it to up to six outputs, providing
amplification and enhancement of the signal to maintain signal quality.
DISTRIBUTION AMPLIFIERS
350 MHz (-3dB) video bandwidth,
fully loaded
Compatible with RGBS, RGsB,
RsGsBs, on HDTV/component video
and digital audio
Gain/peaking adjustments
AC or DC coupling per input
Internal international power supply
Rack mountable metal enclosure
www.extron.com
Advertisement
Related Manuals for Extron electronics Extron DA6 YUV A
Summary of Contents for Extron electronics Extron DA6 YUV A
- Page 1 DA6 YUV A SIX OUTPUT, HDTV/COMPONENT AND DIGITAL AUDIO DISTRIBUTION AMPLIFIER The Extron DA 6 YUV A distribution amplifier splits a signal from a single HDTV/component video source and distributes it to up to six outputs, providing amplification and enhancement of the signal to maintain signal quality. DISTRIBUTION AMPLIFIERS 350 MHz (-3dB) video bandwidth, fully loaded...
-
Page 2: Digital Audio
1U high, full rack width rugged, metal enclosure Internal international power supply PECIFICATIONS VIDEO Gain ... Unity (0.7V), or (0.8V) 100%, switch-selectable Peaking... 0dB or +6dB at 100 MHz, switch-selectable Bandwidth ... 350 MHz (-3dB), fully loaded Differential phase error ... <1.0º, 0 to 100 MHz Differential gain error ...
