OWNER'S MANUAL
Sears Peyton Chaise lounge
Product Code: D71 M80902
UPC Code: 7-22938-07956-8
Date of Purchase: __ / __ / __
If you have any problems with this product, DO NOT RETURN IT TO THE STORE.
CALL OUR CUSTOMER SERVICE HOT-LINE AT
866-391-4868
8am-5pm (EST), Monday-Friday.
View the expanded assortment of outdoor living product on-line at
WWW.lazboyoutdoor.com
and
WWW.sears.com
Page 1 of 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D71 M80902 and is the answer not in the manual?

Questions and answers

Related Manuals for LAZBOY D71 M80902

Summary of Contents for LAZBOY D71 M80902

  • Page 1 OWNER’S MANUAL Sears Peyton Chaise lounge Product Code: D71 M80902 UPC Code: 7-22938-07956-8 Date of Purchase: __ / __ / __ If you have any problems with this product, DO NOT RETURN IT TO THE STORE. CALL OUR CUSTOMER SERVICE HOT-LINE AT 866-391-4868 8am-5pm (EST), Monday-Friday.
  • Page 2 W A R R A N T Y This warranty is a limited warranty, and applies to the original purchase only. Proof of purchase is required. This is a residential warranty and does not apply to commercial use. This collection carries a 5 year limited warranty and is valid from original date of purchase to the original owner (proof of purchase required): NOTE: Glass breakage is not a warranted item.

  • Page 3: Parts List

    CAUTION: Read all the instruction before assembly. Failure to do so may result in faulty assembly and potential injury! Assemble the item on a soft, non-abrasive surface such as a carpet or cardboard to avoid damaging the item. Seek assistance to assemble bulky or heavy items. After final alignment, make sure all bolts, nuts and nut covers are securely tightened.
  • Page 4 Seat Cushion Back Cushion Lumbar Pillow Assembly Steps: Step1: Attach front panel (C) and back panel (D) to right arm (A) with M6x20mm hex head short bolts (G), M6 washers (J). Repeat the same procedure on the left arm (B). (See Figure 1) Figure 1 Step2: Attach seat frame (E) to right arm (A) and left arm (B) with M6x20mm hex head short bolts (G), M6 washers (I).
  • Page 5 Step3: Attach back frame (F) to seat frame (E) with M6x40mm hex head long bolts (H), M6 washers (J) and plastic washer (K). Tighten all bolts with hex wrench (L). Cover all bolts with bolt caps (I). (See Figure 3) Figure 3 Step4: Place seat cushion (M) and back cushion (N) and lumbar pillow (O) in chaise lounge as show figure 4.
