MDA Series
Composite Video Models
MDA 3V
Three Output Composite Video Mini Distribution Amplifier
unique feAtures
Accepts and distributes composite video on female BNC connectors
•
435 MHz (-3 dB) video bandwidth, fully loaded
•
moDeL
MDA 3V
MDA 3V Dual
Dual Three Output Composite Video Mini Distribution Amplifier
unique feAtures
Accepts and distributes composite video on female BNC connectors
•
Two distribution amplifiers in a single enclosure
•
435 MHz (-3 dB) video bandwidth, fully loaded
•
moDeL
MDA 3V Dual
MDA 3AV
Three Output Composite Video with Stereo Audio
Mini Distribution Amplifier
unique feAtures
Accepts and distributes composite video on female BNC connectors
•
Balanced and unbalanced audio on captive screw connectors
•
Audio output gain dip switch to maintain unity gain
•
435 MHz (-3 dB) video bandwidth, fully loaded
•
moDeL
MDA 3AV
MDA 5V
Five Output Composite Video Mini Distribution Amplifier
unique feAtures
Accepts and distributes composite video on female BNC connectors
•
Balanced and unbalanced audio on captive screw connectors
•
Input loop-through
•
435 MHz (-3 dB) video bandwidth, fully loaded
•
moDeL
MDA 5V
514
version DesCriPtion
1x3 Composite Video
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
version DesCriPtion
Dual 1x3 Composite Video
version DesCriPtion
1x3 Composite w/Stereo Audio
version DesCriPtion
1x5 Composite Video
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
