LG LSC27990TT User Manual

Sxs refrigerator
Hide thumbs

Advertisement

website:http://us.lge.com
1-800-243-0000
24 HOURS A DAY, 7 DAYS A WEEK FOR LG CUSTOMER SERVICE
para el Servicio LG (Atenci6n al Cliente) 24 horas al dia, 7 dias a la semana
LSC27990TT
REFRIGERATOR
User's Guide
Please read this guide thoroughly
before operating and keep it handy
for reference at all times.
manuel
le

Advertisement

loading

  Also See for LG LSC27990TT

  Related Manuals for LG LSC27990TT

  Summary of Contents for LG LSC27990TT

  • Page 1 1-800-243-0000 24 HOURS A DAY, 7 DAYS A WEEK FOR LG CUSTOMER SERVICE para el Servicio LG (Atenci6n al Cliente) 24 horas al dia, 7 dias a la semana LSC27990TT REFRIGERATOR User's Guide Please read this guide thoroughly before operating and keep it handy for reference at all times.
  • Page 2: Table Of Contents

    Table of Contents introduction Entry Important safety instructions Identification of parts Installation Where to install Door removal Install the freezer and refrigerator compartment doors Water supply installation Water connection instruction guide Height adjustment External Equipment Connections Operation Setup Adjusting the temperatures and functions Temperature Dispenser...
  • Page 3: Entry

    Entry The model and serial numbers are [bund on the inner case or back of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested infm'mation here and retain this guide as a pernmnent recm'd of your purchase.
  • Page 4: Identification Of Parts

    Child entrapment DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer take off the doors but leavethe warning shelves in place so that children may not easily climb inside. The appliance is not intended for use by young children without supervision. Young children should be supervised to ensure that they do not play with the appliance.
  • Page 5: Where To Install

    Where to install Unstable installation may cause vibration and Strong and even floor noise. If the floor to install the refrigerator on is not even, make the refrigerator level by rotating the height adjusting screw. 2-- _ ..To ensure proper air circulation around the A proper distance from...
  • Page 6: Door Removal

    Door removal Warning Electric Shock Hazard Disconnectelectricalsupplyto refrigeratorbeforeinstalling. Failureto do so could result in death or serious injury. If your entrancedoor is too narrow for the refrigerator to passthrough, remove the refrigerator door and pass the refrigeratorlaterally. Remove lower Removethe lower cover by lifting upward, and then pull cover up the water feed tube while pressingthe releasering O Water Feed Tube...
  • Page 7: Install The Freezer And Refrigerator Compartment Doors

    Pass the Passthe refrigerator laterallythrough the access refrigerator door as shown in the right figure. Install the freezer and refrigerator compartment doors Mount them in the reverse sequence of removal after they pass through the access door. Water supply installation Before •...
  • Page 8: Water Connection Instruction Guide

    Water connection instruction guide Connecting Read all directions carefully before you begin. the refrigerator to a water source Warning Connect to potable water supply only. • Standard screwdriver Tools required • 7/16-inchand 1/2-inch open-end wrenches or two adjustable wrenches • 1/4-inch nut driver •...
  • Page 9 Connect 1. Unplug the refrigerator or disconnect power. the tubing to 2. Turn OFF the main water supply. Turn on the nearest faucet to relieve the water line pressure on the line. It may help to open an outside faucet to allow the water to drain from the line in the house.
  • Page 10 Connect the tubing to Before making the connection to the refrigerator, be sure the refrigerator the refrigerator power cord is not plugged into the wall outlet. • If your refrigerator does not have a water filter, we recommend installing one. If your water supply has sand or particles, that could clog the screen of the refrigerator's water valve.
  • Page 11: Height Adjustment

    Height adjustment if the freezer Level them by insertinga flat ( - type) driver into the groove of the left height adjusting screw and rotating it clockwise ((b). compartment door Height difference is lower than the refrigerator Left height compartment door adjustment screw...
  • Page 12 E×ternal Equipment Connections Antenna Connection Multi-family Dwellings/Apartments Bronze Wire RF coaxial wire (75 ohm) VHF antenna Turn clockwise to tighten. UHF antenna Bronze Wire outdoor antenna Be careful not to bend the bronze wire when connecting the antenna. Single-family Dwellings/Houses (Connect to wall jack for outdoor antenna) •...
  • Page 13: Setup

    Setup When your refrigerator is first installed, allow it to stabilize at normal operating temperatures 2 N3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting the temperatures and functions Water/race Output Dispenser Push Switch -- Dispenser Lamp (Hidden)
  • Page 14: Temperature

    Temperature - You can adjust the freezer and refrigerator temperature. Refrigerator/Freezer Press the TEMPERATURE button. Using the • or • button, select the desired refrigerator. 3 Select the temperature using the _lor • button. Refrigerator temperature options: 46, 41, 37, 34, or 32°F Freezer temperature options: 7, 1, -2, -5, or -8°F IcePlus...
  • Page 15: Dispenser

    Dispenser Crush/Water/Cube - You can select from Crush, Water or Cube options. - When the dispenser is in use, the active option is indicated in the standby screen. - Crush _, Water @, Cube @. Press the DISPENSER button. Select the desired option using the •...
  • Page 16: Menu

    Menu You can select from Information, Gourmet Recipes, Refrigerator, Settings, and Photo Album function. Press the MENU button. 3 Select the menu using the • and • buttons, 4_ Press the SELECT button, 5 You will see the detail menu,...
  • Page 17 - Reception of weather forecast information received and displayed on the screen is subject to vary depending on your region and location of refrigerator. -Thereby LG does not guarantee and will net be held responsible for accuracy of the weather information.
  • Page 18 Anniversary Reminder - Register the anniversary date. Select the Anniversary reminder using the button. < To set a new date > Press the •or • button to select Anniversary Reminder. • Select the month using the • or • button. Press the •...
  • Page 19 Data & "time Setting To set the date and time. Press the • or • button to select Data & Time Setting. Select the menu using Press the • button to select Save. the • or • button. Select the value using the _1 or I1_button.
  • Page 20 Timer To set the alarm. Press the • or • button to select Timer. Select the time using Press the • button the _1 or • button. to select Save. Return to the Information menu....i!_!i_i!_i!_!!_i_!i!!!!!!!i__!_!i_!_!!!_!!_!_!__!ii_!ii!ii_ !!!!iiiiii iiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiiii !ii!i!i!i!i!i!ii_i!ii!i!i_!_!iji!ili_iiii_:!l i!i_!_ii_i!_i_i_ii_ii!_!_ii_!_i_i!i!_!_!_i_ii!_!_i_iiii ¸...
  • Page 21 Select the recipe after selecting the menu category of dish. Gourmet Recipes Refrigerator Select the menu category using the • or • button. You can select the dish Press the • button to select More. using the _1 or • button. You can select the detail menu Press the •...
  • Page 22 You can select from Filter reset, Door alarm, Dispenser light, Manual, and Service Call Refrigerator functions. L1 Filter Reset Reminds you when to replace the filter. < When the filter exchange date is still not due. > Press the • or Vbutton to select Filter Reset.
  • Page 23 < When the filter exchange date is overdue. > Press the • or • button to select Filter Reset. Press the SELECT button. Press the • or I_ button to select Reset, 5 Return to Refrigerator menu.
  • Page 24 Door Alarm This is the function of notifying you every 30 seconds that the refrigerator door is open for more than 1 minute. You can turn the door alarm on or off, Press the • or • button to select Door Alarm. Press the_l orl_ button Press the •...
  • Page 25 Dispenser Light This function controls the LED lamp located on the dispenser. Press this icon turn the dispenser light on or off. Press the • or • button to select Dispenser Light. Press the • or I_ button Press the • button to select Save.
  • Page 26 Owner's Manual You can select from Key Guide, Tem. Adjustment, Child Lock, Weather Forecast, Proper Food Storage, Fridge Maintenance Guide, Freezer Maintenance Guide or Elimination of Odor function. Press the • or •button to select Owner's Manual. Select the menu using the • or Vbutton. 4 Press the SELECT button.
  • Page 27 3. Child Lock 4. Weather Forecast You can check the You can check the Press the •or • Press the • or • button to select detail menu using the button to select detail menu using the Child Lock. 4i or I_ button. Weather Forecast.
  • Page 28 Service Call Info. This shows the number to call for service in the US or Canada. Press the • or • button to select Service Call Info. You can select from Display Image, Display Theme, Power Saver, Settings Screen Backlight/Button Sound, or °C/°FSetting function. Select the menu using the •...
  • Page 29 Display Image You can select the standby screen setting. Press the • or • button Select the desired photo using to select Display Image. the • or • button. Press the •button to select Preview. Press the • button to select Save. You can preview other standby screens using the •...
  • Page 30 L7 Power Saver You can select the Power Saver function. < When Power Saver function is selected > - When selecting [Use of Power Saver], the LCD screen backlight turns off after eclipse of designated time. Press the • or • button Press the •...
  • Page 31 Screen Backlight/Button Sound - You can adjust the screen brightness. - When selecting the button sound, you can turn the button sound on or off. Press the • or • button to select Screen Backlight/Button Sound. Select the brightness value using the •...
  • Page 32 Photo Album You can register a photo or setup the standby screen. < When setting to the standby screen > s" h_fo_m_tio_ Select the desired photo using the • or • button. Press the • button Press the • or • button to to select Display Image.
  • Page 33 < When deleting > Select the desired photo using the • or • button, Press the • button to select Press the • or • button to Delete. select Save. Press the • or • button to select Yes. 5 Return to the standby screen..
  • Page 34 < When registering the photo > When you connect the USB Memory Stick to the USB port, it reads the photo data and adds the album list. < When using USB Memory Stick > When selecting Photo Album and then connecting the USB Memory Stick, import item is activated.
  • Page 35 Lock Lock can be used to disable the buttons and prevent tamperng with the settings. Select Lock using the buttons. - Lock or unlock buttons and dispenser by pressing down the button for 3seconds. - When lock is selected, the dispenser and buttons will be locked and will not operate. - When lock is selected, the lock icon will appear on the screen.
  • Page 36 Other functions Ambient Temperature Display Window. • Temperature is displayed only between 16°F N 120OF (_9ocN 49oc). • Temperature less than 15°F (-9°C) is indicated with LO and temperature more than 121°F (49°C)is indicated with HI. Diagnostic (failure detection) function •...
  • Page 37: Shelf

    Shelf Shelf height The refrigerator compartment shelves are adjustable so you can locate them according adjustment to your needs. • Slide Shelf Pull the shelf ahead and take off it while lifting both front and rear part. • Fixed Shelf, Folding Shelf Lightly lift up the front part of shelf to pull ahead and then take off it while lifting the rear part of shelf.
  • Page 38: Optifresh Temperature Bin

    OptiFresh temperature Method to use You can select the optimum temperature to store some types of foods. -Vegetables, fruits, cold storage items requiring humidity maintenance can be stored under optimal condition by pressing the button. Activate = If you open the refrigerator door, an indicator lamp shows the status of the OptiFresh.
  • Page 39: Location Of Foods

    Location of foods (Refer to Identification of Parts, page 4.) Snack drawer Store small foods such as bread, snacks, etc. Freezer Store various frozen foods such as meat, fish, ice cream, frozen snacks, etc. compartment shelf Store small packed frozen food. Freezer Items stored in the door racks don't stay compartment...
  • Page 40: Storing Foods

    Storing foods • Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. • Do not store food which spoils easily at low temperatures, such as bananasand melons.
  • Page 41: How To Remove And Replace Parts

    How to remove and replace parts Freezer To remove the lamp cover, separate the shelf over the lamp cover and pull the lamp cover compartment forwards @) w hile pressing the bottom side of lamp the lamp cover upwards d_.Turn the bulb counterclockwise.
  • Page 42 To remove the lamp cover, pull the lamp Upper lamp in cover forward while pressing the bottom refrigerator side of the lamp cover upward. Turn the compartment bulb counterclockwise. Use a 40-watt bulb (max.)which can be purchased at a service center. Separate the lamp cover by holding both Lower lamp in...
  • Page 43 Filter We recommend replacing the filter when the replacement water filter indicator light turns on or your water dispenser or ice maker decreases noticeably. After changing the water filter cartridge, reset the water filter status display and indicator light by pressing and holding the BUTTON for 3 seconds.
  • Page 44: General Information

    General information Vacation time During average length vacations, you will probably find it best to leave the refrigerator in operation. Place freezable items in freezer for longer life. When you plan to store the refrigerator, remove all food, disconnect the power cord, clean the interior thoroughly, and block the doors open to prevent mold and mildew.
  • Page 45: Troubleshooting

    Troubleshooting Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Normal Operations Refrigerator Refrigerator Refrigerator control is off. Set refrigerator control.
  • Page 46 Refrigerator Thermostat iskeeping the refrigerator This isnormal. TheRefrigerator goes on compressor ata constant temperature, and offtokeep thetemperature constant. doesnotrun. Temperatures too cold Temperature in the Freezer control is set too cold Adjust the freezer control to a warmer freezer is too cold setting until the freezer temperature is but the Refrigerator satisfactory.
  • Page 47 Sound and Noise Louder sound Today's refrigerators have increased It is normal for sound levels to be higher. levelswhen storage capacity and maintain more Refrigerator is on. even temperatures. Louder sound Refrigerator operates at higher pressures This is normal. The sound will level off as levels when during the start of the ON cycle, the refrigerator continues to run.
  • Page 48 Odors in Refrigerator Interior needs to be cleaned. Clean interior with sponge, warm water, and baking soda. Be sure the soda is completely dissolved so it will not act as an abrasive compound. Foodwith strong odor is in the refrigerator. Cover food completely.
  • Page 49 Dispenser will Ice has melted and frozen around auger Remove ice storage bin, and thaw and the not dispense due to infrequent use, temperature contents. Clean bin, wipe dry, and replace ice. fluctuations, and/or power outrages, in proper position. When new ice is made, dispenser should operate.
  • Page 50 Your LG Refrigerator will be will repaired or replaced, at LG's option, if it proves to be defective in material or workmanship under normal use, during the warranty period (Warranty Period) set forth below, effective from the date ("Date of Purchase") of original consumer purchase of the product.
  • Page 51 LG Electronics Inc. LG Twin Tower, 20, Yoido-Dong, Youngdungpo-Gu, Seoul, 150-721, Korea. http://www.lge.com P/NO : 3828JD8794F Printed in Korea...
