Click
to select the file that will be used for comparison, click the color icon box to
select the desired color. Each file is represented by a capital letter (A through H) with the
file name following the letter.
Diagram N
Temperature Chart
The Temperature Chart displays the data after all readings are completely downloaded.
Cursor Status
The Cursor Status indicates the exact positions of Cursor 1 and 2.
When comparing data
files:
Diagram M shows the
main screen before a file
is retrieved.
Diagram N shows the
main screen with an
example file loaded.
The offset and range
settings can be changed
by moving the indicator
on the yellow rotating
knob (refer to Diagram
O).
16
V7.1 1/08
