Exmark Lazer Z HP Models Parts Manual page 10

BLOWER ASSEMBLY 46", 50", 52" and 56" (cont.)
Item Part No. Description
1 3290-357 Nut, Whizlock 3/8-16 ..............................3
2 323-11 Screw, HH 3/8-16 x 2 1/4 .......................2
3 3256-4 Washer, 3/8 Std .....................................3
4 109-1985 Chute, Blower (46, 50 & 56) ...................1
103-4764 Chute, Blower (52) .................................1
5 109-1122-01 Bumper ..................................................1
6 3290-500 Screw, PPH #10-24 x 5/8 .......................4
7 321-3 Screw, HH 1/4-20 x 5/8 ..........................4
8 32128-33 Nut, Whizlock 1/4-20 ..............................11
9 3229-11 Bolt, Carriage 1/4-20 x 5/8 .....................3
10 1-803075 Screw, CRTH #10-24 x 3/4 (46,50&56) ..3
1-803075 Screw, CRTH #10-24 x 3/4 (52) .............5
11 3290-148 Nut, Whizlock #10-24 (46, 50 & 56)........3
3290-148 Nut, Whizlock #10-24 (52)......................5
12 1-803076 Screw, CRTH 1/4-20 x 3/4 .....................2
13 1-653596-03 Plate, Blower Backing ............................1
14 1-653443-03 Plate, Filler (52)......................................1
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
Exmark black touch up spray paint – gloss black.
Kit 103-0583 is available to repair the welded-on accessory mounting tube on all 44"-72" decks.
Qty. Item Part No.
15 3256-14
16 1-653429
17 109-1024
103-0400
18 3290-500
19 3296-2
20 3256-14
21 109-2041
109-2040
22 109-2035
23 32105-13
24 3229-1
25 323-7
26 103-4752-03
27 114439
9
Description
Washer, #10 Std .................................... 4
Asm, Latch............................................. 2
Asm, Blower (46, 50 & 56) (Includes All
Items From Pg 7 & Items 1-16 & Decals) ...
Asm, Blower (52) (Includes All
Items From Pg 7 & Items 1-16 & Decals) ...
Screw, PPH #10-24 x 5/8....................... 2
Nut, Nyloc #10-24 ................................. 3
Washer, #10 Std .................................... 5
Tube, Lower (46 & 50) ........................... 1
Tube, Lower (52 & 56) ........................... 1
Tube, Upper........................................... 1
Screw, Slotted HH #10-24 x 3/4 ............. 3
Bolt, Carriage 1/4-20 x 3/4 ..................... 2
Screw, HH 3/8-16 x 1 1/4....................... 1
Plate, Reinforcement ............................. 1
Rivet ...................................................... 3
Qty.
1
1
