Exmark Frontrunner Operating Manual page 39

h) If the linkage does not measure 7-3/8" (18.7 cm) or still does not disengage as
desired, remove the bolt that secures the ball joint to the brake lever and
loosen the jam nut next to the ball joint. Rotate the ball joint in half-turns
counter-clockwise until desired disengagement is obtained.
i) Repeat procedure for other side.
4.2.5 Motion control linkage adjustment:
POTENTIAL HAZARD
♦ Engine must be running and drive wheels
must be turning so motion control
adjustment can be performed.
WHAT CAN HAPPEN
♦ Contact with moving parts or hot surfaces
may cause personal injury.
HOW TO AVOID THE HAZARD
♦
rotating components and hot surfaces.
POTENTIAL HAZARD
♦ Raising the unit for service or
maintenance relying solely on mechanical
or hydraulic jacks could be dangerous.
WHAT CAN HAPPEN
♦ The mechanical or hydraulic jacks may
not be enough support or may
malfunction allowing the unit to fall, which
could cause injury.
HOW TO AVOID THE HAZARD
♦
hydraulic jacks for support. Use adequate
jack stands or equivalent
FIGURE 12
WARNING
Keep fingers, hands, and clothing clear of
CAUTION
DO NOT rely solely on mechanical or
34
