2.8 TIRES

Quantity
Tread
Size
Ply Rating
Pressure
Quantity
Tread
Size
Ply Rating
Pressure

2.9 MOWER DECK

2.9.1 Models
Discharge
Cutting Width

2.10 DIMENSIONS

2.10.1 Overall Width:
without deck
deflector up
deflector down
2.10.2 Overall Length:
without deck & floor pan folded
w/52" Deck
w/60" Deck
2.10.3 Overall Height:
2.10.4 Curb Weight:
2.10.5 Tread Width (Center to Center of Drive Wheels):
For 27 HP Kohler Units: 41.4 in. (105.2 cm)
For 20 HP & 23 HP Kohler Units: 38.9 in. (98.8 cm)
2.10.6 Wheel Base (Center of Drive Wheel to Center of Rear Caster Wheel):
For 27 HP Kohler Units: 51.2 in. (130.0 cm)
For 20 HP & 23 HP Kohler Units: 54.1 in (137.4 cm)
2.10.7 Minimum Turning Radius:
For 27 HP Kohler Units: 55.25"
For 20 HP & 23 HP Kohler Units: 56.3"
Drive
Pneumatic (Air-Filled)
2
Turfmate
23 x 10.50-10
4
13 psi (90 kPa)
Drive
Pneumatic (Air-Filled)
2
AT101
24 x 12.00-12
4
9 psi (62 kPa)
(Sold Separately)
FR524
Side Discharge
52 in. (132 cm)
w/52" Deck
49.0 in. (124.5 cm)
53.3 in. (135.4 cm)
64.0 in. (163 cm)
Roll Bar - Up
69.2 in. (175.8 cm)
without Deck
w/52" Deck
w/60" Deck
14
20 HP & 23 HP Kohler Units
Front Caster
Semi-Pneumatic
2
Smooth
9 x 3.50-4
27 HP Kohler Units
Front Caster
Semi-Pneumatic
2
Smooth
9 x 3.50-4
FR604
Side Discharge
60 in. (152 cm)
w/60" Deck
49.0 in. (124 cm)
61.4 in. (156 cm)
72.0 in. (183 cm)
20 & 23 HP Kohler
80.4 in. (204.2 cm)
112.4 in. (285.5 cm) 114.3 in. (290.3 cm)
112.4 in. (285.5 cm) 114.3 in. (290.3 cm)
Roll Bar - Down
50.7 in. (128.8 cm)
911 lbs. (413 kg)
1303 lbs. (591 kg)
1348 lbs. (611 kg)
Rear Caster
(Single Tail Wheel)
Semi-Pneumatic
1
Smooth
13 x 6.5-6
Rear Casters
(Dual Tail Wheel)
Semi-Pneumatic
2
Smooth
13 x 6.5-6
27 HP Kohler
82.3 in. (209.0 cm)
