Summary of Contents for Frigidaire Electric Ranges

  • Page 1 www.fdgidaire.com USA 1-800-944-9044 www.fdgidaire.ca Canada 1-800-265-83...
  • Page 2: Table Of Contents

    Setting broil ............Adjusting oven temperature ........Product Registration Setting oven lockout feature ........Registering your product with Frigidaire enhances our ability Operating oven light ..........to serve you. You can register online at Self-Cleaning ............ 20-21 www,frigidaire,com or by dropping your Product Care &Cleaning...
  • Page 3: Important Safety Instructions

    Read all instructions before using this appliance, Do not attempt to install or operate your appliance until you Ask your dealer to recommend a qualified technician and an have read the safety precautions in this manual. Safety authorized repair service. Know how to disconnect the items throughout this manual are labeled with a WARNING power to the range at the circuit breaker or fuse box in or CAUTION statement based on the risk type.
  • Page 4 = Do not use water or flour on grease fires= smother the fire with a pan lid, or use baking soda, = Storage in or on appliance--flammable materials a dry chemical or foam=type extinguisher. should not be stored in an oven, warmer drawer, near surface units or in the storage = When heating fat or grease, watch it closely.
  • Page 5 SELF-CLEANING OVENS IMPORTANT INSTRUCTIONS USING • Clean in the self=cleaning cycle only the parts YOUR COOKTOP listed in this Use &Care Manual. Before self-cleaning • Know which knob controls each surface heating the oven, remove the broiler pan and any utensils or unit.Place a pan of food on the unit before turning it on, foods from the oven.
  • Page 6: Features At A Glance

    o. 0 Your electric range features include' Electronic oven control with kitchen timer. Interior oven light switch (some models). Left front single (some models) or dual (some models) radiant element control. ii_! _i i _ __ !!__ _ !! _ _ _! !__ _ !!_ _ _! !_ __ !!__ _ !! _ _ _! !__ _ !!_ _ _! !_ __ !!__ _ !! _ _ _! !__ _ !!_ _ _! !_ __ !!__ _ !! _ _ _! !__ _ !!_ _ _! !_ __ !!__ _ !! _ _ _! !_ _;i i!: i ¸ i !i i :;ii! i¸ii ;i ! i;iil ¸ ii¸:ii iiiii i iii i ii i iii i ii i iii i ii i iii i iii i ii i iii i ii i iii i ii i iii i iii i ii i iii i ii i iii i ii i iii i iii i ii i iii i ii i iii i ii i iii i ii;;i Left rear single (some models) or dual (some models) radiant element control.
  • Page 7: Before Setting Oven Controls

    Oven vent location Types of oven racks The oven vent is located under the left side of the Your range may be equipped with one or more of the oven control panel (See Fig. 1). When the oven is on, warm rack styles shown.
  • Page 8: Before Setting Surface Controls

    About the ceramic glass cooktop The ceramic cooktop has radiant surface elements located element ON indicator light below the surface of the glass. The design of the ceramic cooktop outlines the area of the surface element on © underneath. Be sure to match the pan size with the diameter of the element outline on the cooktop and only flat-bottomed cookware should be used.
  • Page 9: Cookware Material Types

    Types of cool(top elements Using proper cookware The ceramic glass cooktop has radiant surface elements The size and type of cookware used will influence the located below the surface of the glass. The patterns on the setting needed for best cooking results. Be sure to follow ceramic glass will outline the size and type of element the recommendations for using proper cookware as...
  • Page 10: Setting Surface Controls

    Single radiant surface elements To operate the single radiant element: Place correctly sized cookware on single radiant surface element. Push in and turn the surface control knob in either £ direction (Fig. 2) to the desired setting (Refer to the Suggested radiant surface element settings table Fig.
  • Page 11: Setting Dual Radiant Surface Elements

    Dual radiant surface elements (some models) Symbols on the backguard are used to indicate which coil of the dual radiant element will heat. The o symbol indicates the inner coil only, The _ symbol indicates both inner and outer coils will heat. To operate a dual radiant element: Place correctly sized cookware on dual radiant surface...
  • Page 12: Setting The Keep Warm Zone

    Keep Warm Zone (some models) Temperature selection - Refer to the keep warm zone recommended food settings table (See Fig. 2). If a The purpose of the keep warm zone is to keep hot cooked particular food is not listed, start with the medium level, foods at serving temperature.
  • Page 13: Home Canning

    Home Canning Be sure to read and observe all the following points when home canning with your appliance. Check with the USDA (United States Department of Agriculture) website and be sure to read all the information they have available as well Radiant surface elements may appear to have cooled as follow their recommendations for home canning after they have been turned off.
  • Page 14: Oven Controls Functions

    READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN. For satisfactory use of your oven, become familiar with the various pad features and functions of the oven as described below. Feature indicator Bake time pad-- Up and down arrow pads-- Use with the lights-- These to enter the length of...
  • Page 15: Setting Silent Control Feature

    Setting a silent control panel When choosing a function, a tone will be heard each time a keypad is pressed. If desired, the control may be programmed for silent operation. The indicator light located above the timer on=off pad will glow while the minute timer is active. To blockthe controls from sounding when any keypad is pressed in the future, press and hold start time keypad for...
  • Page 16: Setting Bake

    Setting bake Setting bake time The oven can be programmed to bake at any temperature The bake time pad sets the amount of time needed for from 170°F to 550°F (77°C to 287°C). The factory preset baking. The oven will turn on immediately and stop automatic bake temperature is 350°F (177°C).
  • Page 17: Setting Bake Time And Start Time

    Setting bake time start time The bake time and start time pads may be used to set the length of baking time and to delay the starting time (delayed timed bake). The oven will turn on at a later time and stop automatically after the set bake time ends.
  • Page 18: Setting Broil

    Setting broil Use the broil feature to cook meats that require direct exposure to radiant heat for optimum browning results. Insert When broiling always remember to arrange the oven racks while oven is still cool. Position the rack as suggested in the broil settings table (See Figs. 1 & 3). To set Broil Arrange the oven rack while oven is still cool.
  • Page 19: Adjusting Oven Temperature

    Adjusting the oven temperature Setting oven lockout The control can be programmed to lock the oven door and Your appliance has been factory calibrated and tested to lockout the oven control pads. ensure an accurate baking temperature. For the first few uses, follow your recipe times and temperature To set the oven lockout feature recommendations...
  • Page 20: Self-Cleaning

    Self=Cleaning A self-cleaning oven cleans itself with high temperatures During the self-cleaning cycle, the outside of the range (well above normal cooking temperatures) which eliminate can become very hot to the touch. DO NOT leave small soils completely or reduces them to a fine powdered ash children unattended near the appliance.
  • Page 21 Setting a self-clean cycle or a delayed start self-clean cycle When the self-clean cycle has completed: 1. The time of day will appear in the display window and the "Clean" and "LOCK" light will continue to glow. Once the oven has cooled down for about 1 HOUR and To start a self-clean cycle immediately without a delay, the "LOCK"...
  • Page 22: Cleaning Recommendation Table

    Cleaning recommendation table Surface type Recommendation * Control knobs Use hot, soapy water and a cloth. Dry with a clean cloth. ,,, Painted body parts For general cleaning, use hot, soapy water and a cloth. For more ,,, Painted decorativetrim difficult soils and buflt-up grease, apply a liquid detergent directly onto * Aluminum, plasticorvinyltrim...
  • Page 23: Cooktop Maintenance & Cleaning

    Cooktop maintenance Cooktop cleaning Consistent and proper cleaning is essential to Before cleaning the cooktop, be sure the controls are maintaining your ceramicglasscooktop, turned to OFF and the cooktop is COOL. Prior to using your cooktop for the first time, apply some of For light to moderate soil: the glass-ceramic cooktop cleaner supplied with your new...
  • Page 24: Cautions For Aluminum Use

    Cooktop cleaning (cont'd) Plastic or foods with a high sugar content: These types of soils need be removed immediately if spilled or melted onto the ceramic cooktop surface. Permanent Damage to the ceramic glass cooktop may occur if you damage (such as pitting of the cooktop surface) may occur use an abrasive type cleaning pad.
  • Page 25: Removing & Replacing Oven Door

    Removing and replacing the lift-off oven door Oven door The door is heavy. For safe, temporary storage, lay the door hinge locations flat with the inside of the door facing down. with oven door fully open, To remove oven door: Open oven door completely (horizontal with floor- See Fig.
  • Page 26: Before You Call Solutions To Common Problems

    ...._ ..... Problem Solution Poor baking results, - Many factors affect baking results. Hake sure the proper oven rack position is used. Center food in the oven and space pans to allow air to circulate, Allow the oven to preheat to the set temperature before placing food in the oven.
  • Page 27 ......... _........Problem Solution Soil not completely removed after self- * Failure to clean bottom, front top of oven, frame of oven or door area cleaning cycle, outside oven seal. These areas are not in the self-cleaning area, but get hot enough to burn on residue.
  • Page 28 Yourapplianceis coveredby a oneyear limitedwarranty.Foroneyearfromyour originaldate of purchase, E lectrolux will payall costsfor repairingor replacinganypartsof this appliancethat prove to bedefectivein materialsor workmanship whensuchapplianceis installed,usedandmaintained in accordance w ith the providedinstructions. Exclusions This warranty does not cover the following: Products with original serial numbers that have been removed, altered or cannotbe readily determined. Product that has been transferred from its original owner to another party or removed outside the USAor Canada.
