Operating Instructions
Stainless Stee! Refrigerator
Temperature
controls
rfJ
ii................. i
_:_ _:_:__:_:_ _:_!Jm/_
...... il ,i,i
:_--Z !
i
The temperature controls are preset in the factory at 37°F
for the fresh food compartment and O°F for the freezer
compartment. Allow 24 hours for the temperature to stabilize
to the preset recommended settings.
The temperature controls can display both the SET temperature
as well as the actual temperature in the flesh food and freezer
compartments. The actual temperature may vary slightly
from the SET temperature based on usage and operating
environment.
Setting either or both controls to OFF stops cooling in both
the freezer and fresh food compartments, but does not shut
off electrical power to the refrigerator.
NOTE: The refrigerator is shipped with protective film covering
the temperature controls. If this film was not removed during
installation, remove it now.
To change the temperature, press Gnd release
the ($) (warmer) or @ (colder) pad. The SETlight
will come on and the displQg will show the set
temperature. To chQnge the temperQture, tap
either the (_ (warmer) or (€)(colder) pod until
the desired temperature is displQged. Fresh food
temperatures con be adjusted between 34°F
and 44°F and the freezer temperatures can be
adjusted between -6°F and +6°F.
Once the desired temperQture hQs been
set, the temperature displQg will return to
the actuQI fresh food and freezer temperatures
after 5 seconds. Several adjustments m(]g
be required. EQchtime gou adjust controls,
allow 24 hours for the refrigerator to reQch
the temperature gou hQveset.
To turn the cooling sgstem off, tGp
the (6") (warmer) pod for either the fresh food
comportment or the freezer until the displag
shows OFF.To turn the unit back on, press
the ($) (colder) pod for either the fresh food
comportment or freezer. The SETlight will
illuminQte on the side gou selected. Then press
the @ (colder) pod agQin (on the side where
the SETlight is illuminQted) and it will go to
the preset points of 0°F for the freezer and 37°F
for the fresh food compartment.
Performance
Air Flow
Sgstem
The Performance Air-Flow Sgstem is designed to
maximize temperature control in the fresh food
and freezer comportments. This unique special
feQture consists of the Air Tower (]long the top
and bQck walls of the fresh food comportment
and the Air Tunnel on the bottom portion of
the freezer reQr wall. Placing food in front of
the louvers on these components will not _ffect
performance.
Although the Air Tower and the Air Tunnel
can be removed, doing so will _ffect temperature
performance. (For remowl instructions, on-line,
24 hours _ d_g, contact us at ge.com or
call 800.444.1845. In C_n_d_, call us _t
1.800.561.3344.)
