Summary of Contents for Voodoo Lab Wahzoo
- Page 1 ® Wahzoo ® Owner’s Manual Version 2.0...
- Page 2 This publication is protected by copyright and all rights are reserved. No part of it may be reproduced or transmitted by any means or in any form without the express prior consent in writing from Voodoo Lab. Voodoo Lab, Wahzoo and Stepwah are trademarks of Digital Music Corp. Rev. 01/2010...
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Controls and Connections VINTAGE . -
Page 4: Introduction
INTRODUCTION Combining the finest classic wah tones, a funk-approved Autowah, and our unique programmable Stepwah, Wahzoo isn’t just another wah pedal. Features: Vintage • Classic Clyde McCoy vocal tone • Adjustable treadle toe position Autowah • Voiced like a traditional wah •... -
Page 5: Controls And Connections
Controls and Connections Wah mode switch. Select between vintage (traditional wah), autowah, and stepwah. Autowah sensitivity. Turn down for hotter pickups, up for longer dwell. Step sequence selector. Select from 4 user programmable sequences. Stepwah only. Bypass footswitch. Switch between effect and true bypass. -
Page 6: Vintage
POWER Wahzoo is powered by a standard 9V battery. Since power is on when you are plugged into the input jack, remember to remove the plug when not in use to conserve battery life. To replace the battery, remove the bottom cover by unscrewing the 4 rubber feet. We do not recommend using carbon batteries. -
Page 7: Autowah
AUTOWAH When you select Autowah from the Wah Mode switch, you get the classic envelope-based effect. But, rather than using a generic bandpass filter, it utilizes the vintage Clyde McCoy voicing. Unlike typical autowah pedals, Wahzoo literally turns into an automatic, dynamically controlled vintage wah! Autowah Sensitivity Since the filter is triggered by how hard or soft you hit the strings, and the general output of... -
Page 8: Creating/Storing Sequences
Creating/Storing Sequences Select which of the 4 presets you’d like to create with the Step Sequence knob. Then turn the Wah Mode knob to Create Seq. Now you can move the treadle to each position you want and hit the Bypass footswitch to save it. -
Page 9: External Footswitch
The Boss FS-6 Dual Footswitch is one example. Use “tip” for tap tempo and “ring” for mode. Of course you can construct your own, or contact Voodoo Lab for the latest available options. -
Page 10: Faq
Wahzoo needs 9VDC regulated to a center negative 5.5 x 2.1mm barrel connector. Where is Wahzoo made? Every Voodoo Lab product is hand built one at a time in our Northern California facility from the finest components. With numerous quality control checks throughout production, our... -
Page 11: Warranty
If the product should become defective within the warranty period, Voodoo Lab will repair it or replace it free of charge, provided it is returned freight prepaid to Voodoo Lab with a valid RMA (return material authorization) number. Return shipping will be paid by Voodoo Lab within the U.S.
