- Page 1 PEDAL POWER DIGITAL User’s Manual www.voodoolab.com...
- Page 2 Copyright ©2011 by Digital Music Corporation. This publication is protected by copyright and all rights are reserved. Voodoo Lab and Pedal Power are trademarks of Digital Music Corp. rev 1.0...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Unpacking Connections DC Power Cables Line 6 Strymon TC Electronic Eventide . Additional Cables About Isolation . Specifications . Warranty . How to Reach Us... -
Page 4: Introduction
All linear, transformer-based power supplies generate heat. While other high- power linear supplies operate at excessively high internal temperatures (which will limit their long term reliability), Pedal Power Digital includes many exclusive design features to keep internal temperatures within proper limits to guarantee long-term reliability. -
Page 5: Unpacking
5.5x2.5mm right angle red barrel (4) Connections Pedal Power Digital is powered directly from AC mains using the supplied detachable line cord. This is a standard computer-type IEC line cord, so it’s easy to obtain a replacement or different length. -
Page 6: Dc Power Cables
5.5x2.5mm barrel cable. This does not match the rating of the supplied Line 6 adapter, but does correctly power these pedals. Note that PODxt & HD, M9, M13 and the JM4 Looper cannot be powered by Pedal Power Digital. - 4 -... -
Page 7: Strymon
Strymon All Strymon pedals (including the larger format Timeline) can be powered from any of the 9V outputs using a standard black 5.5x2.1mm barrel cable. Important: Strymon pedals should only be powered from the 9V outputs. Attempting to power from a 12V output may permanently damage the pedal. Don’t do it, we warned you! TC Electronic TC Electronic’s Nova pedals such as the Delay, Modulator and Reverb can be... -
Page 8: Additional Cables
Additional Cables The DC power cables supplied with your Pedal Power Digital are suitable for most common pedal effects. If you need additional cables, different lengths, reversed polarity, or a special connector, these are available from Voodoo Lab at our online store. -
Page 9: About Isolation
About Isolation Pedal Power Digital has four isolated output sections. This is sometimes referred to as “galvanic isolation” and means that there is no direct electrical connection between each output. Similarly, when you power your effects with batteries, they are also isolated because there is no electrical connection between the batteries. -
Page 10: Specifications
Specifications Input: Standard IEC connector 120V 50/60Hz (North America model) 100V 60Hz (Japan model) 220-240V 50/60Hz (Europe/Australia model) Model and input power are marked on bottom of unit. Outputs: 5.5x2.1mm barrel connectors center negative Short circuit protected. Two 9V or 12VDC - 400mA Two 9VDC - 400mA Physical: 4.9”... -
Page 11: Warranty
Should you experience any difficulty with this Voodoo Lab product, contact us as described below. If it is determined that the product must be returned to the factory for repair, you will be issued an RMA and given shipping and packaging instructions.
