Voodoo Lab ANALOG CHORUS User Manual

Voodoo Lab Guitar Effect Pedals are handcrafted from the finest modern and vintage components. They
are housed in rugged aluminum cases with heavy duty metal switches. True bypass switching is used for
absolutely no loss of tone when the pedal is bypassed. These are the finest effect pedals a musician can buy.
All Voodoo Lab products are manufactured in the U.S.A. by Digital Music Corporation. For more infor-
mation about Digital Music and Voodoo Lab products, please visit our web site at www.voodoolab.com.

Operation

The Voodoo Lab Analog Chorus is a sonic replica of the most sought after chorus of all time, the 1976
Boss CE-1. The original CE-1 had an "intensity" control which was actually speed. With controls for
both speed and intensity, the Voodoo Lab Analog Chorus is capable of a much wider range of sounds.
Here are some suggestions:
1. Normal Chorus: use medium settings of intensity (11 to 2 o'clock) and desired speed. In general,
as you increase the speed you will want to decrease the intensity.
2. Tone Thickening: turn the intensity most of the way down. This will add a lush analog doubling.
3. Leslie: turn both the intensity and speed most of the way up. This gives the tone of a rotating
speaker or Leslie.
Plugging into the input jack turns on the power to your Analog Chorus.
To preserve battery life, disconnect the input cable when not in use.

Battery

The Voodoo Lab Analog Chorus is powered by a single 9V battery. To replace the battery, remove the
four screws which secure the bottom cover. Replace only with an Alkaline-type battery.

External Power

The Voodoo Lab Analog Chorus can be powered externally with a regulated 9VDC power supply,
eliminating the need for the internal battery. The external power supply connector is a 5.5x2.1mm
barrel with center negative.

Warranty Information

Digital Music Corporation warrants this product against any defects that are due to faulty material or
workmanship for a period of five years from the date of original retail purchase. This warranty does not
include damage to the product resulting from accident or misuse. This warranty is given to the original
purchaser only and it is not assignable to any other person.
