HOOD PARTS
For Models: KHTU105RSS0, KHTU165RSS0
(Stainless)
1
(Stainless)
Illus.
Part
No.
No.
1
8191020 Instruct, Install
8191019 Wiring Diagram
6
8190560 Damper
7
8190358 Damper, Hood
8
8190559 30" Model
8191027 36" Model
9
4360156 Nut
10
4360005 Washer
12
8189602 Transformer, 120V
13
8191022 Support
14
8190403 Screw
15
4360062 Relief, Strain (2)
16
8190562 Cover, Wire
30" or 36" WALL CANOPY
DESCRIPTION
Literature Parts
