  • Page 1 User Manual ENDOCHECK™ Test System...

  • Page 2: Table Of Contents

    CONTENTS INTRODUCTION ............... 2 SPECIFICATIONS ............3 III. RECEIPT, INSPECTION & RETURN........ 4 USE OF THE ENDOCHECK™ TEST SYSTEM ....5 APPLICATIONS..............6 WARRANTY ..............7 VII. TECHNICAL SUPPORT ........... 7...

  • Page 3: Introduction

    INTRODUCTION EndoCheck™ Features The EndoCheck™ Test System is a portable kit designed for qualitative and quantitative testing of light sources and fiber light cables used in a rigid endoscopy environment, and is intended to be used by trained service technicians. The kit does not check rigid endoscopes – only fiber cables & light sources.

  • Page 4: Specifications

    SPECIFICATIONS BC Biomedical Model 401025 Light Meter Light level units & ranges Lux: 0-2,000, 0-20,000, & 0-50,000 Foot-Candles: 0-200, 0-2,000, & 0-5,000 Resolution .1 FC or 1 Lux Accuracy +/- 5% of full scale Detector Precision photo diode with color-correction filter;...

  • Page 5: Receipt, Inspection & Return

    III. RECEIPT, INSPECTION & RETURN Inspect the outer box for damage. • Carefully unpack all items and check to see that you have the following items: • o EndoProjector™ o 401025 Light Meter o Light Meter adapter If you note physical damage, or if the unit fails to function according to specification, inform the •...

  • Page 6: Use Of The Endocheck™ Test System

    USE OF THE ENDOCHECK™ TEST SYSTEM Qualitative Analysis of Fiber Light Cables with the EndoProjector ™ 1. Turn the light source off. 2. Connect the fiber light cable to be inspected to the light source. Connect the other end to the EndoProjector ™.

  • Page 7: Applications

    APPLICATIONS The EndoCheck™ Test System is a versatile product. Several suggested applications and methods for using it follow. Suspected bad fiber cables Connect a known-good or new fiber cable of the same type as the suspect one, and take a reading with the light meter.

  • Page 8: Warranty

    BC Biomedical will, for a period of twelve (12) months from date of purchase, replace or repair any defective test system, if the fault is due to a manufacturing defect.
