CONTENTS MANUAL REVISION RECORD .........2 II. INTRODUCTION ............3 III. SPECIFICATIONS ............ 4 IV. RECEIPT, INSPECTION & RETURN......6 V. CONTROL SWITCHES AND TERMINALS....7 VI. WARRANTY ............10 VI. TECHNICAL SUPPORT.......... 10...
MANUAL REVISION RECORD This record page is for recording revisions to your MAXISIM 2000 User Manual that have been published by BC Biomedical or its authorized representatives. We recommend that only the management or facility representative authorized to process changes and revisions to publications: •...
II. INTRODUCTION BC Biomedical’s MaxiSim 2000 is a high performance simulator designed to simplify patient monitor testing, and is designed to be used by trained service technicians. It simulates electrocardiogram, respiration, dynamic blood pressure and static temperature. It offers three preprogrammed automatic test modes (ECG rate, ECG performance rate, and BP level), plus a built-in ECG lead continuity test.
III. SPECIFICATIONS ECG General Lead Configuration: 12-lead simulation derived from one resistively divided analog signal. RL, RA, LA, LL, V1-6 Output Impedance Limb leads: 500 or 1000 ohms to RL V Leads: 1000 ohms to RL High Level Output: 0.5 V/mV of low level (Lead II) Normal Sinus Rates: 30, 60, 80, 120, 180, and 300 BPM...
Page 6
Arrhythmia Selections Atrial Fibrillation 1 & 2 Premature Atrial Contraction Premature Ventricular Contraction (PVC) Early PVC R on T PVC Multifocal PVCs Bigeminy Bigeminy Run of 5 PVCs Ventricular Tachycardia Ventricular Fibrillation Second Degree Type 2 Right Bundle Branch Block Asynchronous Pacemaker Fetal/Maternal ECG Respiration...
Repack the unit in a manner to ensure that it cannot shift in the box during shipment. BC Biomedical’s product warranty is on page 8 of this manual. The warranty does not cover freight charges. C.O.D. will not be accepted without authorization from BC Biomedical or its representative.
CONTROL SWITCHES AND TERMINALS Front Panel MaxiSim 2000 Patient Simulator 1. Power Switch Turns the power on and off. 2. LCD Display Sets LCD display waveform values. Use the right key to enter units, and the left key to enter tens.
Page 9
Connectors terminals. Snap-to-banana adapters for the terminals are axiSim supplied with the M 2000. NOTE Use only BC Biomedical 11. Battery Micro jack for connecting the 9V AC Adapter plug-in power Eliminator plug-in power supply transformer supply transformer supplied with the unit.
Page 10
AC Battery Eliminator Adapter if you do not BC Biomedical’s AC Adapter plug-in power supply transformer allows you intend to use the MaxiSim 2000 anywhere a standard electrical outlet is MaxSim 2000 for an extended period of time.
BC Biomedical will, for a period of twelve (12) months from date of purchase, replace or repair any defective analyzer, if the fault is due to a manufacturing defect. In no event will BC Biomedical or its local representatives be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of or inability to use the MaxiSim 2000 Patient Simulator, even if advised of the possibility of such damages.
