Care and Cleaning
Damp objects stick to
cold metal surfaces. Do not touch interior
metal surfaces with wet or damp hands.
Figure 2
HOSE
ADAPTOR
Figure3
If leaving freezer door]
open while on vacation, make certain /
that
children
cannot
get into the /
freezer and become entrapped.
J
Some upright freezers are frost-free and defrost automatically, but should be cleaned
occasionally,
Between
Defrostings
To avoid frequent defrosting, occasionally use a plastic scraper to remove frost.
Scrape with a pulling motion. Never use a metal instrument to remove frost.
Defrosting
It is important to defrost and clean freezer when 1/4 to Y2inch of frost hasaccumulated.
Frost may tend to accumulate faster on upper part of the freezer due to warm, moist
air entering the freezer when the door is opened. Remove food and leave the door
open when defrosting the freezer.
On upright models with a defrost drain (Figure 1), remove drain plug on the inside
floor of the freezer by pulling straight out. To access external drain tu be on models
with a base panel, first remove the two screws from the base panel. Locate the
drain tube near the left center under the freezer. Place a shallow pan under the
drain tu be. Defrost water will drain out. Check pan occasionally so water does not
overflow. A Y2inch garden hose adapter can be used to drain the freezer directly
into a floor drain. If your model is not equipped with an adapter, one can be
purchased at most hardware stores. Replace the drain plug when defrosting and
cleaning are completed.
If the drain is left open, warm air may enter freezer.
On chest models with a defrost drain, place a shallow pan or the Divider/Drain
Pan (some models) beneath the drain outlet (Figure 2). A Y2inch garden hose
adapter can be used to drain the freezer directly into a floor drain (Figure 3). If your
model is not equipped with an adapter, one can be purchased at most hardware
stores. Pullout the drain plug inside the freezer, and pull offthe outside defrost drain
plug (Figure 4). Defrost water will drain out. Check pan occasionally so water does
not overflow. Replace the drain plugs when defrosting is completed.
• On modelswithout a defrostdrain, placetowels or newspapersonthe freezer bottom
to catch the frost, The frost will loosenand fall, Removetowels and/or newspapers,
• If the frost issoft, remove it by using a plastic scraper, If the frost is glazed and hard,
fill deep panswith hot water and placethem on the freezer bottom, Close the freezer
door, Frost should soften in about 15 minutes, Repeat this procedure if necessary,
Cleaning
the Inside
After defrosting, wash inside surfaces of the freezer with a solution of two tablespoons
of baking soda in one quart (1,136 litres) warm water, Rinse and dry, Wring excess
water out of the sponge or cloth when cleaning in the area of the controls, or any
electrical parts,
Wash the removable partsand door basket with the baking soda solution mentioned
above, or mild detergent and warm water. Rinseand dry. Never usemetallicscouring
pads, brushes, abrasive cleaners, or alkaline solutions on any surface. Do not wash
removable parts in a dishwasher.
Cleaning
the Outside
Wash the cabinet with warm water and mild liquid detergent. Rinse well and wipe
dry with a clean soft cloth. Replace parts and food.
Vacation and Moving
Tips
Short Vacations: Leavethe freezer operating during vacationsof lessthan three weeks,
Long Vacations: If the freezer will not be used for several months, remove all food
and unplug the power cord, Clean and dry the interior thoroughly, To prevent odor
and mold growth, leave the freezer door open slightly, blocking it open if necessary,
Moving: Disconnect the power cord plug from the wall outlet, Remove foods, then
defrost, and clean the freezer, Secure all loose items such as base panel, baskets,
and shelves by taping them securely in place to prevent damage, In the moving
vehicle, secure freezer in an upright position, and secure to prevent movement, Also
protect outside of freezer with a blanket, or similar item,
7
