Frigidaire FFU11FC2CW1 Factory Parts Catalog

Frigidaire ffu11fc2cw1: supplementary guide
Hide thumbs Also See for FFU11FC2CW1:
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual See also: Use and Care Manual
P08F0009.EPS P08D0350.eps P08C0652.eps P08S0331.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FFU11FC2CW1
Series
134A
Color
WHITE
Volts
115
Wiring Diagram 216940600
Owner's Guide 216802800
Market
N. AMERICA
Energy Guide
216795205
UPRIGHT FREEZER
Publication No.
5995399259
03/11/25
(EN/SERVICE/LR)
365
Copyright
Model No.
FFU11FC2CW1
2003 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

Related Manuals for Frigidaire FFU11FC2CW1

Summary of Contents for Frigidaire FFU11FC2CW1

  • Page 1 P08F0009.EPS P08D0350.eps P08C0652.eps P08S0331.eps ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917 Product No. FFU11FC2CW1 Series 134A Color WHITE Volts Wiring Diagram 216940600 Owner's Guide 216802800 Market N. AMERICA Energy Guide 216795205 UPRIGHT FREEZER Model No. FFU11FC2CW1 Publication No.
  • Page 2 Publication No: 5995399259 FFU11FC2CW1 DOOR 11/03...
  • Page 3 216503200 216524300 5303212828 216807701 08009392 5309950074 216403700 5303161215 # Functional Parts * Non-Ilustrated Parts FFU11FC2CW1 DOOR DESCRIPTION Gasket-door, white Panel-inner door, frzr Panel-outer door, white Nameplate, white Door Stop Washer, sealing Handle, recessed, white Screw, door stop mtg, 4.0 x 0.7-19.7, flat hd, metric...
  • Page 4 Publication No: 5995399259 11/03 FFU11FC2CW1 CABINET P08C0652...
  • Page 5 216629600 216036600 216835200 5303283898 09948773 5303305324 216795205 # Functional Parts * Non-Ilustrated Parts FFU11FC2CW1 CABINET DESCRIPTION Screen-drain Fan Blade Breaker Kit w/corners Breaker Kit w/corners, 22.13" long, top or bottom Motor, fan, 115 V Knob, temp control Gasket, evap cover...
  • Page 6 Publication No: 5995399259 FFU11FC2CW1 SYSTEM 11/03...
  • Page 7 216596800 31 # 216100106 5306594529 5303272328 216629700 216347800 216036600 08037849 216854002 216486800 216502500 # Functional Parts * Non-Ilustrated Parts FFU11FC2CW1 SYSTEM DESCRIPTION Condenser Strap-evap/heater, aluminum, (2) Drier-filter Harness-main Heater-defrost Evaporator Heat Exchanger Insulator-evap, styrofoam Insulator-evap, styrofoam Thermostat, defrost Timer-defrost Bracket...
