Frigidaire FFU14K2CW1 Service Data Sheet

ELECTRICAL CIRCUIT
Power
N
L
See Diagram
Blk
Blu
Compressor
Pink
Temp Warning
Cold
Red
Alarm
Control
Buzzer
Off On
Red
Door
Switch
Power On
EC40
SYSTEM SCHEMATIC
Condenser
High Side
Process Tube
Drier
Capillary
Low Side Process Tube
SS1
IMPORTANT
If any green grounding
wires are removed dur-
ing servicing,
Wh
must be returned to
their original position
and properly secured.
WIRING DIAGRAM
Interior
Light
Evaporator
Compressor
Suction
Tube
Discharge
IMPORTANT SAFETY NOTICE
The information provided herein is
designed to assist qualified repair
personnel only. Untrained persons
they
should not attempt to make repairs
due to the possibility of electrical
shock. Disconnect power cord
before servicing.
INSTALLATION
This product is designed for "free standing installation only" and three
inches of clearance must be provided on all sides of the freezer for air
circulation.
The freezer should be positioned on a solid floor, and the front of the
cabinet should be raised just enough to provide easy door closure when
open about half way.
REFRIGERANT CHARGE AND ELECTRICAL SPECIFICATIONS
Refer to serial plate.
C23
TEMPERATURE CONTROL
7.0°F cut in, -5.0°F cut-out @ number 1 setting.
PERFORMANCE (Control at number 1 setting)
Room Ambient
Freezer Compartment Temperature
Percent Running Time
*Wattage Range (Last
Suction Pressure (Cut-in, cut-out), PSIG
High Side Pressure (Last
Specifications subject to change without notice.
*For complete performance data by model refer to service manual.
216903500
SERVICE DATA SHEET
MANUAL DEFROST
UPRIGHT FREEZER
70°F
5 to 10°F
40-55%
1 ⁄ of cycle) 70-110
3
15-0
1 ⁄ of cycle), PSIG 105-115
3
90°F
5 to 10°F
45-60%
70-110
15-0
140-160
PD643
