Maitenance; Specifications; Especificaciones; Mantenimiento - Craftsman 214.50145 Operator's Manual

• When the ra ;aches maximum
extension, olios by-passed back into
the reservoir to prevent an over-
extended ram stroke and possible
damage to the jack.
• Opening the release valve allows oil
to flow back into the reservoir. This
releases hydraulic pressure on the
ram, which result in lowering the
saddle.
HOW TO USE YOUR JACK
RAISING THE JACK
° Close release valve by turning the
handle clockwise.
° Block the vehicle's wheel for lifting
stability.
° Refer to the vehicle manufacturei
owners manual to locate approved
lifting points on the vehicle. Position
jack so that the saddle (see Fig. 3)
is centered under the load at an
appropriate lift point.
• Pump jack handle until saddle NEARS
contact with the vehicle. Check to see
that the saddle is centered and will
contact the load lifting point firmly.
©
!
.. One Stroke Speedy Lift
MAINTAINING OIL LEVEL
Important Note: when adding or
replaceing oil, ALWAYS use a good
grade Hydraulic Jack oil. DO
NOT use Hydraulic Brake Fluid,
Alcohol, Glycerine, Detergent Motor
Oil or dirty oil. Use of an improper
fluid can cause serious internal
damage to your jack.
° Continue to pump the jack handle to
lift the vehicle to the desired height.
After lifting, support the load with
appropriately rated vehicle support
stands BEFORE working on the
vehicle.
LOWERING THE JACK
° Open the release valve VERY
SLOWLY by turning the handle
counterclockwise.
Caution: Keep hands and feet clear of
the jack hinge mechanism and ground
contact area when lowering the load!
SPECIFICATIONS
Normal Capacity: 3-1/2 Ton
Jack's Dimensions:
27-1/4" x 13-1/4" x 6-1/2"
Full Lifting Range: 5-3/4" - 20"
One Stroke Lifting Range:
5-3/4" ~ 17-3/4"
Operating Force: 123 lbs
Oil Capacity: 150 cc
Net Weight: 82 Ibs
ADDING OIL
° Position the jack on level ground
and fully lower the saddle.
Remove oil filler plug (see
Figs.4 and 5.)
• Oil should be filled to the level
of the oil filler plug hole. If low,
add oil as needed.
Compruebe ue_0Porte esta
centrado y q'_te har,_
contacto contra el punto de elevaci6n
determinado firmemente.
° ContinQe bombeando con la
manivela del gato hidr__ulicb para
elevar el vehfculo a la altura deseada.
Una vez levantada, sujete la carga
con los medios apropiados ANTES
de trabajar con ella.
BAJANDO el Gato _r_ulico
Abra la vMvula de liberaci6n MUY
LENTAMENTE girando en contra del
sentido del reloj la manivela del gato
hidr&ulico.
ATENCION- iMantenga las
extremidades lejos del
mecanismo del gato hidrAulicoy
de la zone de contacto en el
suelo mientras ba je la carga!.
ESPECIFICACIONES
Capacidad Normal: 3-1/2 Ton
Dimensiones: 27-1/4" x 13-1/4" x 6-1/2"
Rango De Elevaci6n: 5-3/4" ~ 20"
Rango De Elevaci6n Con Un Movimiento: 5-3/4" ~ 17-3/4"
Fuerza De Funcionamiento: 123 libras
Capacidad Dep6sito De Aceite: 150 cc
Peso Neto: 82 libras
O
Etevacl6n r_pida con
un rnovlmlento
27-1/4"
MANTENIMIENTO DEL NIVEL
DE ACEITE
Nota Importante: al afiadir o cambiar el
aceite SIEMPRE use aceite para Gatos
Hidr_.ulicos de graduaci6n correcta. NO
utilice Lfquido de Frenos HidrAulicos,
Alcohol, Glicerina, Aceite Limpiador de
Motores o Aceite sucia. El uso de Ifquidos
inapropiados puede causar serios dafios .
internos a su gato hidrAulico.
AI_IADIR ACEITE
° Colocar el gato en posici6n horizontal
sobre el suelo y descienda el soporte
completamente. Quite el tap6n de
Ilenado (Fig. 4 y 5).
. El niveldel aceite deber& Ilegar hasta la
boca del tap6n de Ilenado.En caso de que
se encuentre bajo el nivel, afiada aceite
hasta el nivel indic, ado.
7
