AC line voltage requirements for the HP Disk Array XP1024 (DKU)
XP1024 hardware
Table 18 (page 73) lists the basic AC power requirements for a 50-amp,
single-phase, XP1024 DKU.
Table 18. 50-Amp, 50 or 60 Hz, Single-Phase DKU Operation
Parameter
Rated line current per power cord
(Arms)
Number of power cords
Number of circuit breakers
Recommended circuit breakers
* 60 Hz only.
Table 19 (page 73) lists the basic AC power requirements for a 30-amp,
single-phase XP1024 DKU.
Table 19. 30-Amp, 50 or 60 Hz, Single-Phase DKU Operation
Parameter
Rated line current per power cord
(Arms)
Number of power cords
Number of circuit breakers
Recommended circuit breakers
* 60 Hz only.
Nominal Rated Voltage (VAC)
200 208 220
*
22.3 21.6 20.3
2 2 2
2 2 2
50 A 50 A 50 A 50 A 50 A
Nominal Rated Voltage (VAC)
200 208 220
*
13.5 13.0 12.3
4 4 4
4 4 4
30 A 30 A 30 A 30 A 30 A
230 240
19.4 18.6
2 2
2 2
230 240
11.7 11.2
4 4
4 4
