3. Press Enter until you see the system name and login prompt, as shown here, then log in as
4. Run the nasQuickStart command and follow the on-screen instructions.
Note:
5. If no DNS server is available, or if you prefer not to use the DNS server, execute the
6. Repeat the above steps on each NAS server.
7. To log out of the system, type:
HP StorageWorks NAS 8000 Dedicated Storage High Availability, Solution Integration Manual (SIM)
admin. No password is required.
hp StorageWorks NAS 8000
NAS OS v1.x.x
localhost login:admin
You are prompted to:
Select and configure the Management Interface
— If a bond is selected, select slave interfaces
— Enable/disable DHCP
— If DHCP is not selected, enter the IP address, netmask, broadcast address, and
gateway address.
Enter the hostname
Enter the DNS domain name and server addresses
Configure remaining interfaces (like management interface, above)
Enter the timezone information
Scan for VA arrays
Settings are applied as you enter them.
following commands, where:
— XXX represents IP address information.
— *name represents the name provided by the system administrator.
— domain represents the domain name provided by the system administrator.
setSystemHostsFileEntry quorumservername XXX.XXX.XXX.XXX domain
setSystemHostsFileEntry node1name XXX.XXX.XXX.XXX domain
setSystemHostsFileEntry node2name XXX.XXX.XXX.XXX domain
exit
