Planning Worksheets

The following topics should be reviewed in a planning session with the customer prior to
installation:
The planning worksheets in this section provide space to collect the information needed to
install the system. The blank worksheets are also included on the NAS 8000 Documentation
CD.

Available Disk Space Spreadsheets

For the installation specialist: Before you begin the storage planning process with the
customer, you must know the amount of available disk space on their system. If you have not
received information about available disk space from the HP sales representative, use the
capacity calculation spreadsheet for the customer's array model to calculate how much space
will be available for use.
This spreadsheet calculates the available disk space on the NAS 8000 HA system by
subtracting the space required for RAID redundancy and active spares from total raw capacity.
Note:
http://csps.fc.hp.com/mass/disk.htm
Non-confidential Tables 3-6, below, can also be used to determine available disk space.
VA71xx supports up to 15 drives. VA7410 support up to 105 drives. You can extrapolate
higher capacity/drive count values from these tables.
Note:
space on the system when it is installed before building the storage system.
HP StorageWorks NAS 8000 Dedicated Storage High Availability, Solution Integration Manual (SIM)
Available disk space
LUN, volume group and file volume requirements
High-availability settings
Network settings
These HP Confidential spreadsheets are available only to HP and resellers at:
The numbers in these spreadsheets and tables are approximate. Verify the actual available
