Shipping Configurations
The HP StorageWorks NAS 8000 components are delivered either pre-installed in a rack, or
separately to be racked on-site. For large configurations, you will need two racks and a rack tie
kit. Tape library and UPS components are shipped separately and must be racked on-site.
Racked systems:
Figure 10: Racked System
HP StorageWorks NAS 8000 Dedicated Storage High Availability, Solution Integration Manual (SIM)
Racked systems are shipped with the NAS server, storage array(s) and disk enclosure(s)
racked in an HP E-Series rack.
The Quorum server is shipped in a separate package and must be racked on-site.
Accessories and documentation are shipped in a separate package.
WARNING:
The rack is heavy. Use care when taking the rack off of the pallet. Three people
are required for this step. Always use the anti-tip feet in the rack base.
Installation Guide
39
