Configuration Setup
1
Figure 3-1: Ethernet connectors
Table 3-1: Ethernet Network Connectors
Item




Note: Connect a loopback cable to any of the NAS B2000 Ethernet ports
that are not configured for use.
3-4
2
Remote Insight Lights-Out Edition board Ethernet port
(RILOE Eth)
NIC Ethernet port 1 (Eth 1) used for data
NIC Ethernet port 0 (Eth 0) used for data
3
Description
NAS B2000 Quick Start Guide
