Honeywell PRO TH4110B Owner's Manual

Hide thumbs Also See for PRO TH4110B:

Advertisement

Quick Links

Download this manual See also: Operating Manual, Installation Manual

Advertisement

loading

Related Manuals for Honeywell PRO TH4110B

Summary of Contents for Honeywell PRO TH4110B

  • Page 2 CAUTION: EQUIPMENT DAMAGE HAZARD. To prevent possible compressor damage, do not operate cooling system when outdoor temperature is below 50°F (1O°C). Read save these instructions ® U.S. Registered Trademark. Patents pending. Copyright @ 2005 Honeywell Internationalinc. All rights reserved.
  • Page 3 PRO TH4110B Programmable Thermostat Appendices About your new thermostat Thermostat features ....Batte W replacement ...... In case of difficulty ...... Programming at a glance ....Customer assistance ...... Quick reference to controls ... .4 Accessories ........Quick reference m display ....Limited warrant3_ ......
  • Page 4 Operating Manual Congratulations on the purchase of your new Honeywell thermostat, llt has been designed to give you many years of reliable service and easy-to-use, push-button climate control. Festu • Separately programmable weekday/weekend schedules. • One-touch temp control overrides program schedule at any time.
  • Page 5 PRO TH41 lOB Programmable Thermostat Your new thermostat is pre-programmed and read?, to go.All you have to do is set the time and day.Then check tile settings bek)w and change if needed: Set time and day (required for proper operation) ........
  • Page 6 Operating Manual Digital display (see page 5) Temperature adjustment (see pages 11-13) Set: Press to set time/day/ schedule Held" Press to override programmed temperature control Run: Press to resume program schedule System switch (see page 7) Cool: Thermostat controls only the cooling system.
  • Page 7 PRO TH41 lOB Programmable Thermostat Low battery warning Current day/time (see page 6) (see page 15) Current inside /Temperature setting temperature /(see pages 11-13) Heat On/Cool On Current program period (If flashing, see page 14) Wake/Leave/Return/Sleep (see pages 10-11 )
  • Page 8 Operating Manual Press SET,then adjust time SETbutton, Press then press or T to set the clock time. Press the SETbutton, then press A or Y to select day of the week. Press RtlR to save & exit. Press SET,then select current day Note: If the display flashes Set Clock, the thermostat will follow your settings...
  • Page 9 PRO TH41 lOB Programmable Thermostat The SYSTEM s witch can be set to con- trol your heating or cooling system, depending on the season. • Heat:Thermostat controls only the heating system. • Cool: Thermostat controls only the cooling system. • Off: Heating and cooling systems are off.
  • Page 10 Operating Manual Set the FARswitch to Auto or On. In '%uto" mode (the most commonly used setting), the fan runs only when the heating or cooling system is on. If set to "On," the fan runs continuously: Use this setting for improved air circulation, or [br more efficient air cleaning.
  • Page 11 PRO TH41 lOB Programmable Thermostat It's easy to program your system [br maMmum energy savfl_gs.You can program four time periods each day,with different settings lbr weekdays and weekends. WAKE Set to the time you awaken and the temperature you want 6:06 am during the morning,...
  • Page 12 Operating Manual • This thermostat is pre-set to use EnergyStar * program settings.We recolnmend these settings, since the}, can reduce your heating/cooling expenses by as much as 33');,. (See next page to adjust times and temperatures of each time period.) Heat (Men-Fr0 Cool (Mon-Fri) Heat (Sat-Sun)
  • Page 13 PRO TH41 lOB Programmable Thermostat Press SET 3 times, then adjust time Press SET until Set Schedule is dispktyed. Press A or Y to set your weekdavWake thee (Mon-Fri), then press SET. Press A or Y to set the temperature this time period, then press SET.
  • Page 14 Operating Manual Pressto Press A or Y to immediately adjust the temporarily adjust temperature temperature.This will temporarily override the temperature setting for the current time period. The new temperature will be maintained only until tile next programmed time period Press to resume program schedule begins (see page 10).
  • Page 15 PRO TH41 lOB Programmable Thermostat Pressto permanently adjusttemperature Press HSL[:I to permanently adjust the temperature.This will override the temperature settings lbr all time periods. The "Hold" feature turns off the program schedule and allows you to adjust the thermostat manually, as needed. Press to resume program schedule Whatever temperature...
  • Page 16 Operating Manual This feature helps prevent damage to the compressor in the air conditioning or heat pump system. Damage can occur if the compressor is re- started too soon after shutdown.This feature R)rces the compressor to wait R:)ra few minutes befbre restarting. During the wait time, the message Cool On Message flashes until safe (or Heat On if you have a heat pump) will...
  • Page 17 PRO TH41 lOB Programmable Thermostat Grasp and pull to Install [resh batteries immediately removethermostat, when the REPLACE BATT w arning begins "" flashing.The warning flashes about two months before the batteries are Turn thermostat over, depleted. insert fresh AA alkaline batteries, then reinstall Even it"the warllJng does not appear,...
  • Page 18 Operating Manual ]if you have difficult3/with your thermostat, please try tile suggestions below. Most problems quickly and easily: lye corrected Display is blank Make sure fresh AA alkaline batteries are correctly installed (see page 15). Heating or Set system switch to Heat (see page 7). Make sure the temperature cooling system set higher than the inside temperature.
  • Page 19 PRO TH41 lOB Programmable Thermostat Temperature Make sure heating and cooling temperatures are set to acceptable ranges: settings de net • Heat: 40 ° to 90°F (4,5 ° to 32°C). change Cooh 50 ° to 99°F (10 ° to 37°0). Compressor protection feature is engaged.
  • Page 20 To save time, please note your model to find model number and date code number and date code beR)re calling. Accessories For accessories, please call Honeywell Customer Care toll-free at 1-800468-1502. Cover plate ....Part No. 50002883-001 (Used to cover marks left by old thermostats.}...
  • Page 21 Honeywell shall repair or replace it (at Honeywell's option). [f the product is defective, (i) return it, with a bill of sale or other dated proof of purchase, to the place from which you purchased it;...
  • Page 22 HONEYWELL SHALL NOT BE LIABLE FOR ANY LOSS OR DAMAGE OF ANY KIND, INCLUDING ANY INCIDENTAL OR CONSEQUENTIAL DAMA(;ES RESULTING, DIRECTIX OR INDIRECTIX, FROM ANY BREACH OF ANY WARRANTY,EXPRESS OR [MPLIED, OR ANY OTHER FAILURE OF THIS PRODUCT.
  • Page 23 This warren D, gives you specific legal rights, and you may have other rights which vary from state to state. ]ifyou have a W questions concerning this warranty, please write Honeywell Customer Relations, 1985 Douglas Dr, Golden ValleB MN 55422 or call 1-800-468-1502. ]in Canada, write Retail Products ON15-02H, Honeywell I.imited/...
