Agitator Servicing; To Check Agitator Assembly; To Replace Agitator Assembly - Kenmore Power-Mate KC50XBZRZU01 Owner's Manual

Electrical Shock Or Personal Injury
Hazard
Disconnect electrical supply before
servicing or cleaning the unit.
Failure to do so could result in elec-
trical shock or personal injury from
cleaner suddenly starting.
TO CHECK AGITATOR
ASSEMBLY
When brushes
___ re worn to the
level of the base
support bars,
replace the
agitator
assembly.
Base Support Bars
TO REPLACE AGITATOR
ASSEMBLY
1. Remove Power-Mate ®cover, belt and
agitator assembly. See =To Remove Belt" in
BELT CHANGING AND AGITATOR
CLEANING.
2. Replace Agitator.
3. Replace belt, agitator assembly and
Power-Mate ®cover. See =To replace belt" in
BELT CHANGING AND AGITATOR
CLEANING.
12
