Start Here
Epson Expression
1

Unpack Your Scanner

1
Remove everything from the box.
Scanner
Software
CD-ROM
If you have the Photo version of the scanner, the following items are
also included.
2
Remove all the tape and packing material inside and around the
product.
2

Install the Software

Wait! You must install your software before connecting the scanner to
your computer. The installation may take several minutes. Be sure to close
all open programs and turn off any virus protection programs.
EPSON Scan works with Windows
OS X 10.2.x, 10.3.9 to 10.4.x. Follow the steps in the section for your
operating system.
Windows
1
Insert the Scanner Software CD-ROM in your CD-ROM or DVD drive.
With Windows Vista, if you see the AutoPlay window, click Run
Epsetup.exe. When you see the User Account Control screen, click
Continue.
2
Read the license agreement and click Agree. The Software Installation
screen appears.
10000XL
®
Scanner
Power cord
Adobe
Photoshop
Elements
CD-ROM
Transparency
Transparency
unit
guide
Film holders
(two of each type)
®
Vista,
User's Guide
USB cable
MonacoEZcolor
®
CD-ROM
®
LaserSoft Imaging
SilverFast
CD-ROM
XP, and 2000, and Macintosh
®
Ai 6
®
®

Advertisement

Table of Contents
loading

Summary of Contents for Epson EXPRESSION 10000XL

  • Page 1: Unpack Your Scanner

    Unpack Your Scanner Remove everything from the box. Scanner Software CD-ROM If you have the Photo version of the scanner, the following items are also included. Remove all the tape and packing material inside and around the product. Install the Software Wait! You must install your software before connecting the scanner to your computer.
  • Page 2 Follow the on-screen instructions to register your scanner, then remove the CD-ROM. If you want to use any of the bonus software included with your scanner, insert the CD-ROM for the software you want to install, and follow the on-screen instructions. Some software may not be compatible with Windows Vista.
  • Page 3: Install The Transparency Unit

    Install the Transparency Unit If you have the Photo version of the scanner, you need to install the transparency unit. Fully open the scanner’s document cover, then lift it straight up. Lower the transparency unit onto the scanner, so that the pins fit into the holes as shown.
  • Page 4: Connect The Scanner

    USB hub. If you’re using IEEE 1394 (FireWire Plug one end of the IEEE 1394 cable (not included) into the scanner’s IEEE 1394 port. Then plug the other end into the IEEE 1394 port on your computer.
  • Page 5: Getting The Most From Your Scanner

    For details, see the on-screen guide included with the software. First, scan the target image using EPSON Scan: Turn on your scanner, then place the reflective target included with MonacoEZcolor face-down on the scanner glass. (Use the larger, 5 7 color chart as the target.) Put it in the upper-left corner of the glass, as...
  • Page 6 Click the Auto Adjust button to apply your color profile. (The button is located near the bottom of the main EPSON Scan screen; you may have to scroll down to see it.) Then click Scan. When scanning completes, close EPSON Scan to view your scanned image in Photoshop Elements.
  • Page 7: Optional Equipment

    Connects the scanner to your network, making it accessible to multiple users. You can purchase supplies and accessories from an Epson authorized reseller. To find the nearest reseller, call 1-800-GO-EPSON (1-800-463-7766). Or you can purchase online at www.epsonstore.com (U.S. sales) or www.epson.ca (Canadian sales).
  • Page 8 Fax: (941) 387-7574 * Toll or long distance charges may apply. Epson is a registered trademark and Exceed Your Vision is a trademark of Seiko Epson Corporation. Expression is a registered trademark of Epson America, Inc. General Notice: Other product names are for identification purposes only and may be trademarks of their respective owners.
