Rack Installation Guide Information Update

This document updates information included in your system Rack

Installation Guide.

Figure 1 updates Figure 1-8 in the Rack Installation Guide. Your system's

cable tray connects to the system back panel as shown in Figure 1.

Figure 1. Installing the Cable-Management Arm

back of rack

back of system

cable tray

mounting tabs (2)

October 2007

Table of Contents

Do you have a question about the PowerEdge R900 and is the answer not in the manual?

Page 1 Rack Installation Guide Information Update This document updates information included in your system Rack Installation Guide. Installing the Cable Tray and Cable Management Arm Figure 1 updates Figure 1-8 in the Rack Installation Guide. Your system’s cable tray connects to the system back panel as shown in Figure 1. Figure 1.
Page 2 Securing Cables to the Cable-Management Arm When routing cables through the cable-management arm, be sure and use the separate Velcro strap provided in the rack kit to tightly secure the cable bundle to the cable basket elbow on the CMA. See Figure 2. Figure 2.
