AF-A098E
ROOM AIR CONDITIONER
INSTALLATION AND
OPERATION MANUAL
KLIMAGERÄT
INSTALLATIONS UND
BEDIENUNGSANLEITUNG
CLIMATISEUR DOMESTIQUE
MANUEL D'INSTALLATION
ET D'UTILISATION
ACONDITIONADOR DE AIRE
MANUAL DE INSTRUCCIONES
DE MANEJO
AR CONDICIONADO
MANUAL DE INSTALAÇÃO
E UTILIZAÇÃO
KAMER AIR CONDITIONING
INSTALLATIE-EN
BEDIENINGSHANDLEIDING
Advertisement
Related Manuals for Sharp AF-A098E
Summary of Contents for Sharp AF-A098E
- Page 1 AF-A098E ROOM AIR CONDITIONER INSTALLATION AND OPERATION MANUAL KLIMAGERÄT INSTALLATIONS UND BEDIENUNGSANLEITUNG CLIMATISEUR DOMESTIQUE MANUEL D'INSTALLATION ET D'UTILISATION ACONDITIONADOR DE AIRE MANUAL DE INSTRUCCIONES DE MANEJO AR CONDICIONADO MANUAL DE INSTALAÇÃO E UTILIZAÇÃO KAMER AIR CONDITIONING INSTALLATIE-EN BEDIENINGSHANDLEIDING...
-
Page 2: Table Of Contents
PARTS NAMES AND DIMENSIONS ..E-1 This INSTALLATION AND OPERATION MANUAL explains the proper use of your new INSTALLATION INSTRUCTIONS ..E-1 Sharp Air Conditioner. Read these instruc- OPERATION INSTRUCTIONS ..... E-5 tions carefully before installing or operating your air conditioner. The INSTALLATION MODES OF OPERATION ..... - Page 3 INSTRUÇÕES DE INSTALAÇÃO ..P-1 correctamente o seu novo ar condicionado da Sharp. Leia com atenção as instruções INSTRUÇÕES DE UTILIZAÇÃO ..P-5 antes de instalar ou utilizar o seu ar condicionado. O MANUAL DE INSTALAÇÃO MODOS DE FUNCIONAMENTO ..P-6 E UTILIZAÇÃO deve ser guardado num lugar...
-
Page 4: Parts Names And Dimensions
PARTS NAMES AND DIMENSIONS Front panel Grille Air filter (behind the grille) Up/Down air flow adjustment louvres Left/Right air flow adjustment louvres Cabinet Ventilation lever Control panel Stopper screws (on left and right side) Power cord and plug DIMENSIONS A (mm) B (mm) C (mm) 583 (centre 590) - Page 5 INSTALLATION INSTRUCTIONS LOCATION Install the air conditioner to the opening dimensions shown below. Never install the unit where each of the air inlet is blocked. The air conditioner should be installed with a strong external support to minimize noise and vibration, and for the purpose of safe installation, repair, replacement and secure positioning.
- Page 6 INSTALLATION INSTRUCTIONS INSTALLATION WARNING: Grille Turn off and disconnect the unit before working. Hinge Open the grille (Fig.1) by gently pulling the arrow marked portion. Remove the air filter (Fig.2) from the front panel. Fig.1 Air filter Unscrew the screw fixing the front panel to the chassis.
- Page 7 INSTALLATION INSTRUCTIONS When drainage is necessary If water drainage is necessary in high humid- ity district, or if you do not like the splashing Rubbur cap sound of the non-drain function, remove the rubber cap on the bottom of the chassis. Cut the rubber cap in cross, working from the bot- tom and remove the rubber pieces with a Fig.6...
-
Page 8: Operation Instructions
OPERATION INSTRUCTIONS PRECAUTIONS POWER CORD REPLACEMENT WARNING: Use only the manufacturer specified power cord, parts code QACC-A217JBE0 for its replacement. Replacemant should be conducted by a qualified technician or a serviceman. Consult your dealer for detail informa- tion concerning replacement of the power cord. WAIT FOR 3 MINUTES BEFORE RESTARTING THE COOLING OPERATION Whenever you turn the air conditioner OFF, wait for at least three (3) minutes before restarting the unit. -
Page 9: Modes Of Operation
MODES OF OPERATION HOW TO OPERATE Control panel Auto swing switch Thermostat knob Selector knob Ventilation lever SELECTOR KNOB Use to select the desired mode. (COOLING , FAN or OFF) Both the fan and cooling operation Cooling for sleeping comfort with low are off. - Page 10 MODES OF OPERATION THERMOSTAT KNOB Use to adjust the desired room temperature setting. The air conditioner will automatically maintain the room temperature according to the THERMOSTAT setting. Turning the knob clockwise will lower room temperature. You need to experiment to find out which setting suits you most.
-
Page 11: Cleaning And Maintenance
CLEANING AND MAINTENANCE WARNING: Turn off and unplug the unit before performing any cleaning or maintenance. CLEANING THE FILTER If the filter is clogged with dust, the amount of air flow will be reduced, resulting in poor cooling performance. The filter should be cleaned every 10 days. At the beginning of every cooling season or if the air conditioner has not been used for a long period, clean the filter before starting to oper- ate the unit. -
Page 12: Before Calling For Servlce
BEFORE CALLING FOR SERVlCE IF YOUR AIR CONDITIONER DOES NOT OPERATE PROPERLY, PLEASE CHECK THE FOLLOWING ITEMS BEFORE CALLING FOR SERVICE. AIR CONDITIONER DOES NOT OPERATE AT ALL • Is the power cord loosened or unplugged? • Is the fuse blown or has the circuit breaker been tripped? •... - Page 13 SHARP CORPORATION Osaka, Japan Printed in Thailand TINS-A507JBR0 TL 7MO 1...
