JVC KD-R621 Instructions Manual
  1. Manuals
  2. Brands
  3. JVC Manuals
  4. Car Receiver
  5. KD-R621
  6. Instructions manual

JVC KD-R621 Instructions Manual

Cd receiver
Hide thumbs Also See for KD-R621:
Table of Contents

Advertisement

Quick Links

Having TROUBLE with operation?
Please reset your unit
Refer to page of How to reset your unit
Vous avez des PROBLÈMES de fonctionnement?
Réinitialisez votre appareil
Référez-vous à la page intitulée Comment réinitialiser votre appareil
Dear Customer,
This apparatus is in conformance with the valid
European directives and standards regarding
electromagnetic compatibility and electrical safety.
European representative of Victor Company of
Japan, Limited is:
JVC Technical Services Europe GmbH
Postfach 10 05 04
61145 Friedberg
Germany
EN, FR
© 2010 Victor Company of Japan, Limited
CoverRear_KD-R621_003A_f.indd 1-2
CoverRear_KD-R621_003A_f.indd 1-2
Cher(e) client(e),
Cet appareil est conforme aux directives et
normes européennes en vigueur concernant la
compatibilité électromagnétique et à la sécurité
électrique.
Représentant européen de la société Victor
Company of Japan, Limited:
JVC Technical Services Europe GmbH
Postfach 10 05 04
61145 Friedberg
Allemagne
1110DTSMDTJEIN
KD-R621
CD RECEIVER / RÉCEPTEUR CD
For canceling the display demonstration, see page 4. / Pour annuler la démonstration des
affichages, référez-vous à la page 4.
For installation and connections, refer to the separate manual.
Pour l'installation et les raccordements, se référer au manuel séparé.
INSTRUCTIONS
MANUEL D'INSTRUCTIONS
ENGLISH
FRANÇAIS
GET0708-003A
[E/EU]
11/2/10 4:09:11 PM
11/2/10 4:09:11 PM
