Regency P33 Sunrise
WARNING:
If the information in these instructions are not followed exactly,
a fi re or explosion may result causing property damage,
personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other fl ammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualifi ed
installer, service agency or the gas supplier.
Tested by:
918-757a
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
Gas Fireplace
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
™
Installation Manual
MODEL: P
www.regency-fi re.com
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical switch:
do not use any phone in your
building.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fi re department.
Owners &
33
S-NG4 Natural Gas
33
P
S-LP4 Propane
01/11/11
Advertisement
Table of Contents
Related Manuals for Regency Sunrise P33S-NG4
Summary of Contents for Regency Sunrise P33S-NG4
- Page 1 Owners & Regency P33 Sunrise ™ Installation Manual Gas Fireplace MODEL: P S-NG4 Natural Gas S-LP4 Propane www.regency-fi re.com WARNING: FOR YOUR SAFETY If the information in these instructions are not followed exactly, What to do if you smell gas: a fi...
- Page 2 To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The P33 Sunrise™ ® has been designed to provide you with all the warmth and charm of a fi re at the fl ick of a switch.
-
Page 3: Manufactured Mobile Home Requirements
This appliance can only be used with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases, unless a certifi ed kit is used. (Kit # 434-970) Ensure that structural members are not cut or weakened during installation. Regency P33 Sunrise™ Gas Fireplace... -
Page 4: Table Of Contents
The Warranty: Limited Lifetime ........47 Gas Pipe Pressure Testing ..........29 Conversion from NG to LP ..........30 DC Spark Box Battery Replacement ......32 DC Spark Box Replacement........32 Optional Wall Thermostat ...........33 Optional Remote Control ..........33 GT remote features .............33 Regency P33 Sunrise™ Gas Fireplace... -
Page 5: Safety Label
DOOR SEAL: Please check that VENTING: Use listed Direct Vent Pro and others as listed in the manual or Regency Direct Vent System. Only for direct discharge without duct connection. This appliance the door is properly sealed must be installed in accordance with the manufacturer's installation instructions and with local codes, if any; if not, follow the current ANSI Z223.1 in the USA or the current CAN 1-B149 in Canada. -
Page 6: Requirements
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. Regency P33 Sunrise™ Gas Fireplace... -
Page 7: Dimensions
DIMENSIONS UNIT DIMENSIONS Regency P33 Sunrise™ Gas Fireplace... -
Page 8: Installation
fi tted as per Venting instructions. 5) Inspect the venting system annually for blockage and any signs of deterioration. 6) Venting terminals shall not be recessed into a wall or siding. Regency P33 Sunrise™ Gas Fireplace... -
Page 9: Installation Checklist
11) Final check. Flat on Wall Corner Recessed into Wall/Alcove Before leaving this unit with the customer, the Corner installer must ensure that the appliance is fi ring correctly and operation fully explained to customer. Regency P33 Sunrise™ Gas Fireplace... -
Page 10: Clearances
(air space) to combustible materials are not recessed into combustible construction. adhered to. It is of greatest importance that this fi replace and vent system be installed only in accordance with these instructions. Regency P33 Sunrise™ Gas Fireplace... -
Page 11: Mantel Clearances
Note: Ensure the paint that is used on the mantel and the facing is "heat resistant" or the paint may discolour. MANTEL LEG CLEARANCES Combustible mantel leg clearances from side of unit as per diagram: Regency P33 Sunrise™ Gas Fireplace... -
Page 12: Framing & Finishing
fl ame package, carbon, blue fl ames etc. These are not product related issues. Regency P33 Sunrise™ Gas Fireplace... -
Page 13: Framing Dimensions
36" (914mm) Rigid 32" (812mm) Flex Vent Centerline Height* 30" (762mm) Rigid 26" (660mm) Flex Gas Connection Height* 1 1/2" (38mm) Gas Connection Inset* 4" (102mm) Gas Connection Width* 3" (76mm) * Measured from base of unit. Regency P33 Sunrise™ Gas Fireplace... -
Page 14: Unit Assembly Prior To Installation
There are 5 vent systems approved for use with the P33S: the Regency Direct Vent Flex System for Horizontal Terminations only and the Simpson Dura- ®... -
Page 15: Exterior Vent Termination Requirements
* Clearance in accordance with local installation codes and the requirements of the gas supplier 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly 3 feet (91cm) above - if within 10 feet (3m) horizontally Regency P33 Sunrise™ Gas Fireplace... -
Page 16: Regency
#8 x 1-1/2" drill point, stainless steel (4) Notes: 1) Liner sections should be continuous without any joints or seams. ® 2) Only Flex pipe purchased from Regency may be used for Flex installations. Alternate Horizontal Termination Caps MINIMUM... -
Page 17: Rigid Pipe Venting Systems
American Metal Products Ameri Vent Direct Vent, Security Secure Vent , Selkirk Direct-Temp. AstroCap is a proprietary trademark of FPI Fireplace ® Products International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. Regency P33 Sunrise™ Gas Fireplace... -
Page 18: 4" X 6-5/8" Rigid Pipe Cross Reference Chart
Offset Support 46DVA-ES (N/A - FPI) 4DT-OS SV4SU Wall Thimble-Black 46DVA-WT 4DT-WT 4DWT 4DWT SV4RSM TE-4DE90 Wall Thimble Support/Ceiling Support 46DVA-DC SV4PF TE-4DE90B Firestop Spacer 46DVA-FS 4DT-FS 4DFSP 4DFS SV4BF Trim Plate-Black 4DT-TP 4DFPB 4DCP SV4LA Regency P33 Sunrise™ Gas Fireplace... - Page 19 Note: Horizontal runs of vent must be level, or have a 1/4” rise for every 1 foot of run towards the termination. Never allow the vent to run downward - this could cause high temperatures and may present a possible fi re hazard. Regency P33 Sunrise™ Gas Fireplace...
-
Page 20: Rigid Pipe Venting Arrangements
Firestops are required at each fl oor level and whenever passing through a wall. • Maintain clearances to combustibles. • Vent must be supported at offsets. Note: Must use optional rigid pipe adapter when using rigid vent systems (Part # 510-994). Regency P33 Sunrise™ Gas Fireplace... -
Page 21: Vertical Termination With Co-Linear Flex System
46DVAGK 3" Co-linear Adapter with fl ashing Outer Pipe with Kit# 946-563 Air Intake Pipe Length Co-Linear Flex Rigid Pipe Adaptor Adapter # 510-994 with Kit# 946-563 45 Elbow Inner Pipe Adapter with Kit# 946-563 Regency P33 Sunrise™ Gas Fireplace... -
Page 22: Venting Arrangements - Vertical Terminations
VENTING ARRANGEMENTS - VERTICAL TERMINATIONS with Co-linear Flex System for both Residential & Manufactured Homes into Masonry Fireplaces Horizontal Distance (Feet) Horizontal Distance (Feet) Horizontal Distance (Feet) The shaded area in the diagrams show the allowable vertical terminations. Regency P33 Sunrise™ Gas Fireplace... -
Page 23: Horizontal Terminations
8"(0.2m) • Horizontal vent must be supported every 3 feet. 2’ (0.6m) • Firestops are required at each fl oor level and whenever passing through a wall. Minimum Minimum Simpson Dura-Vent Center-Line Flex Kit Center-Line Regency P33 Sunrise™ Gas Fireplace... - Page 24 8 feet total horizontal. 3' Max. 4' Min. 6' Max. Please note minimum 4' Max. 6' Min. 7' Max. 1 foot between 90 5' Max. 8' Min. 8' Max. elbows is required. Regency P33 Sunrise™ Gas Fireplace...
- Page 25 5' Min. 1 foot between 90 required. 5' Min. 8' Max. 6' Min. elbows is required. 6' Max. 6' Min. For additional vertical venting with 2 x 90 elbows, refer to "Rigid Pipe Venting Arrangements" Section. Regency P33 Sunrise™ Gas Fireplace...
- Page 26 4' Min. 5' Max. 7' Min. horizontal. 5' Min. 6' Max. 8' Min. Please note min. 1 foot 6' Min. 7' Max. 9' Min. between 90 elbows is 7' Min. 8' Max. 10' Min. required. Regency P33 Sunrise™ Gas Fireplace...
-
Page 27: Unit Installation With Horizontal Termination
Wall ner pipe connection. Failure to do so may Thimble (Part # 620-926) over the vent result in drafting or performance issues not pipe. covered under warranty. Silicone (red RTV) is optional. Regency P33 Sunrise™ Gas Fireplace... -
Page 28: Unit Installation With Vertical Termination
fl ashing to the roof with roofi ng rails, detector. Do not use open fl ame for leak slide storm collar over the pipe section and testing. seal with a mastic. Diagram 2 Regency P33 Sunrise™ Gas Fireplace... -
Page 29: Pilot Adjustment
1) Gas on/off knob 2) Manual high/low adjustment 3) Pilot Adjustment 4) Thermocouple Connection - option 5) Outlet Pressure Tap 6) Inlet Pressure Tap 7) Pilot Outlet 8) Main Gas Outlet 9) Alternative TC Connection Point Regency P33 Sunrise™ Gas Fireplace... -
Page 30: Conversion From Ng To Lp
Firebox base Reinstall new burner orifi ce LPG stamped #56 and tighten. 5) Pull off the pilot cap to expose the pilot orifi ce. (Diagram 5) Diagram 1 Pilot Orifi ce Pilot Cap Diagram 5 Regency P33 Sunrise™ Gas Fireplace... - Page 31 12) Check that the screw is clean and if necessary remove dirt. 13) Flip the screw (Fig. 3). Fig. 6 WARNING! Also check that the pilot and main burner injectors Fig.3 are appropriate for the gas type. Regency P33 Sunrise™ Gas Fireplace...
-
Page 32: Dc Spark Box Battery Replacement
(Diagram 5) Diagram 2 4) Reinstall battery cover on DC Spark Box. 5) Reinstall faceplate (refer to steps 5 and 6 of the faceplate installation instructions). Diagram 5 6) Replace DC Spark Box and reverse steps. Regency P33 Sunrise™ Gas Fireplace... -
Page 33: Optional Wall Thermostat
50 Ft. 16 GA. 32 Ft. GT REMOTE FEATURES 18 GA. 20 Ft. 20 GA. 12 Ft. 22 GA. 9 Ft. Note: Regency Profl ame systems include a white and black wall cover & switch. Regency P33 Sunrise™ Gas Fireplace... -
Page 34: Aeration Adjustment
Openings for electrical connections CAUTION: Label all wires prior to disconnection 120 V. Power IN when servicing controls. Wiring errors can cause improper and dangerous operation. Millivolt Wires 2-5/16” (59mm) 7/16” (11mm) 4-1/2” (114mm) 6” (152mm) Regency P33 Sunrise™ Gas Fireplace... -
Page 35: Gt Remote Wiring Diagram
12. Using the two (2) screws provided secure the cover plate to the Receiver. J-Box Receiver Slider Switch Wall Plate REFER TO CODING INSTRUCTIONS IN THIS MANUAL Extra wires not used spade connectors Green wire Red wire White wire Black wire Regency P33 Sunrise™ Gas Fireplace... -
Page 36: Installing The Optional Fan
8) Secure the control plate assembly with 1 the bracket clip on the underside of the screw as shown in Diagram 6. fi rebox. Check that no wire will touch the hot surfaces. Diagram 2. Diagram 6 Diagram 2 Regency P33 Sunrise™ Gas Fireplace... -
Page 37: Optional Refl Ective Panel Installation
4) With the top panel in place - install back panel. The back panel fi ts under the top panel, push the top panel up to fi t back panel into position. (Diagrams 3) Diagram 3 Back Panel Regency P33 Sunrise™ Gas Fireplace... -
Page 38: Glass Crystal
Blue Glass Crystals or optional Ceramic Spa Stones. NOTE: Only the supplied and approved pebbles are to be used. Use of any other type of pebbles or material can create a danger and will void warranty. Regency P33 Sunrise™ Gas Fireplace... -
Page 39: Standard Flush Door Installation
Use the hook to pull the spring out until you can put the hook into the slot on the bottom door bracket. Repeat for 2nd spring. See diagram 3. To remove the fl ush door, reverse the above steps. Diagram 3 Diagram 1 Regency P33 Sunrise™ Gas Fireplace... -
Page 40: Faceplate Installation
5) The top of the faceplate has a fl ange that hooks over the top of the Heat Defl ector Top of Firebox Diagram 2 fl ush door. Heat Defl ector Diagram 6 Flange Faceplate Support Control Shield Mounting Frame Diagram 3 Regency P33 Sunrise™ Gas Fireplace... - Page 41 6) Hook the fl ange on the faceplate over the top of the fl ush door and gently lower the faceplate into place until it rests against the faceplate supports as shown in Diagrams 7 & 8. Diagram 7 Faceplate Diagram 8 Faceplate Support Diagram 9 Regency P33 Sunrise™ Gas Fireplace...
-
Page 42: Operating Instructions
2) Press "OFF" on the remote control. cleaner and DO NOT ATTEMPT TO CLEAN THE GLASS WHILE IT IS HOT. 3) Turn the gas control knob to the "OFF" posi- tion to turn off the pilot. Regency P33 Sunrise™ Gas Fireplace... -
Page 43: Copy Of Lighting Plate Instructions
3) Turn off all electric power to the appliance if service is to be performed. You may shut off the pilot during prolonged non use periods to conserve fuel. DO NOT REMOVE THIS INSTRUCTION PLATE 918-583 Regency P33 Sunrise™ Gas Fireplace... -
Page 44: Maintenance
2 screws marked TP on the valve. 9) Drop the thermocouple or thermopile down from the bracket and pull it out of the unit. 10) Reinstall the new ones in reverse order. Regency P33 Sunrise™ Gas Fireplace... -
Page 45: Valve Tray Replacement
DC spark box located in front of the valve. 13) Undo the "gas out" fl are nut with a 13/16" wrench. 14) Undo the "gas out" fl are fi tting with an 11/16" wrench. Regency P33 Sunrise™ Gas Fireplace... -
Page 46: Parts List
Valve Assembly P33S-NG4 SIT Packaged 434-576/P Valve Assembly P33S-LP4 SIT Packaged 341-525 Burner Assembly NG/LP c/w Cap Outerbox Assembly Firebox Assembly 433-538 Flush Door Assembly Complete 940-088/P Glass (Flush) 904-691 U-Clip 936-155 Glass Gasket FAN SWITCH ASSEMBLY Regency P33 Sunrise™ Gas Fireplace... -
Page 47: Warranty
It is the general practice of FPI to charge for larger, higher priced replacement parts and issue credit once the replaced component has been returned to FPI and evaluated for manufacturer defect. The authorized selling dealer is responsible for all in-fi eld service work carried out on your Regency ®... - Page 48 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency Sunrise is a trademark of FPI Fireplace Products International Ltd. © Copyright 2010, FPI Fireplace Products International Ltd. All rights reserved. Printed in Canada...
