- Page 1 Xerox Document Services Platform Series Getting Ready for the DocuSP Installation DocuSP version 3.x 701P38969 October 2002...
- Page 2 Printed in the United States of America. XEROX® and all Xerox product names mentioned in this publication are trademarks of XEROX CORPORATION. Other company trademarks are also acknowledged.
-
Page 3: Table Of Contents
About the worksheets..................4 W-1: Solaris operating system worksheet............5 W-2: Xerox Security worksheet..............8 W-3: Xerox Document Services Platform software worksheet ...... 9 W-4: System configuration worksheet ............11 W-5: Xerox Document Services Platform software and gateways worksheet....................14 W-6: Novell NetWare gateway installation worksheet ........ -
Page 5: Table Of Contents
The Getting Ready for the DocuSP Installation guide has been developed for you to use in the gathering of technical data that will be required by the Xerox personnel during installation of your customer’s Document Services Platform hardware and software. -
Page 6: Available Worksheets
DocuSP software. · Worksheet W-4: System configuration This information is used by the Xerox service representative to connect the DocuSP controller to the Xerox printer and is a required worksheet. · Worksheet W-5: Xerox Document Services Platform software and gateways... - Page 7 DOCUSP 3.x · Worksheet W-8: SNMP Gateway Installation This information can be used by either the Xerox Service Representative or the customer to set up the SNMP Gateway after the gateway has been installed and licensed. · Worksheet W-9: Client workstations...
-
Page 8: About The Worksheets
The At Install column will indicate information that only the Xerox service representative can enter at the time of install. The pre-determined or customer value column will be grayed out when an at install value exists. -
Page 9: W-1: Solaris Operating System Worksheet
DOCUSP 3.x W-1: Solaris operating system worksheet The following information is used by the Xerox service representative during the installation of the Solaris operating system on the DocuSP controller. Data Element Customer Value Hostname DHCP Ipv6 Kerberos Security Network configuration... - Page 10 NlS server name: The name of the server acting as the network information service holding user information. Subnetwork: A “YES” answer to this query indicates that your customer’s network is divided into segments or “subnets.” In this XEROX DOCUMENT SERVICES PLATFORM SERIES GETTING READY FOR THE DOCUSP INSTALLATION...
- Page 11 NOTE: If another machine is not identified as the default router the controller will automatically take over the main router function This may noticeably slow down processing on the network. XEROX DOCUMENT SERVICES PLATFORM SERIES GETTING READY FOR THE DOCUSP INSTALLATION...
-
Page 12: W-2: Xerox Security Worksheet
DOCUSP 3.x W-2: Xerox Security worksheet The following information is used by the Xerox service representative during the installation of the DocuSP software to enable the appropriate level of security for the DocuSP software. Refer to the descriptions below for more information on each security feature. -
Page 13: W-3: Xerox Document Services Platform Software Worksheet
UNIX clients, or PC clients using TCP/IP protocol, is installed. At the client workstation, native UNIX print commands such as lpr, the Xerox Print Client utility, or the Xerox Document Submission software for UNIX can then be used to submit jobs to the controller. - Page 14 Client hostname: The hostname of the workstation that will be used to submit jobs to the controller. This entry is used in the hosts.equiv file that is created during install. XEROX DOCUMENT SERVICES PLATFORM SERIES GETTING READY FOR THE DOCUSP INSTALLATION...
-
Page 15: W-4: System Configuration Worksheet
DOCUSP 3.x W-4: System configuration worksheet The following information is used by the Xerox service representative during the set up and configuration of the dC105 diagnostics screen. Data Element Customer Value Server serial number Printer serial number supported Xerox printer only... - Page 16 Sun Microsystems banner screen at the beginning of the Solaris OS software installation. The service representative’ will enter both data elements on this worksheet for reference during the installation process. XEROX DOCUMENT SERVICES PLATFORM SERIES GETTING READY FOR THE DOCUSP INSTALLATION...
- Page 17 Windows document submission tools or transparent print drivers through TCP/IP, queue names must be limited to 14 characters due to limitations by the Solaris lp admintool. XEROX DOCUMENT SERVICES PLATFORM SERIES GETTING READY FOR THE DOCUSP INSTALLATION...
-
Page 18: W-5: Xerox Document Services Platform Software And Gateways Worksheet
DOCUSP 3.x W-5: Xerox Document Services Platform software and gateways worksheet The following information is used by the Xerox service representative during the installation of the DocuSP software and to install the licenses for the selected features. Indicate which gateways and other software features have been selected by the customer to be installed and licensed on the controller. -
Page 19: W-6: Novell Netware Gateway Installation Worksheet
Novell Server (PC) to the DocuSP controller (Sun). The information in this worksheet is gathered by your customer’s network administrator or the Xerox Systems Analyst at each Novell server that will be submitting documents to the DocuSP controller. At install, the service representative uses this information to set up and configure the QServer gateway software on the controller. - Page 20 W-6 data element definitions This section defines the data elements determined by the network administrator or the Xerox Systems Analyst during the setup of the NetWare Gateway on each Novell Server that will be transferring documents from Novell clients to the controller.
- Page 21 Xerox server is ready. Enter the name for this queue in this column. Novell print server name: The print server submits the job from the queue to the Xerox server. Enter the name for this server in this column. Novell print server password: The Novell Network administrator password.
-
Page 22: W-7: Appletalk Gateway Installation Worksheet
An icon showing two double opposing arrows represents EtherTalk 2.0 (Phase 2). Should the EtherTalk 2.0 icon appear, double-click on it and see if an Internet router is found. If one is found, a panel appears XEROX DOCUMENT SERVICES PLATFORM SERIES GETTING READY FOR THE DOCUSP INSTALLATION... - Page 23 Network Server will reside and is also assigned in the Load AppleTalk statement. This refers to the parameter “Apple-big- zone”. Note: If the network will be running both Novell NetWare and AppleTalk, the frame type must be Ethernet_II. XEROX DOCUMENT SERVICES PLATFORM SERIES GETTING READY FOR THE DOCUSP INSTALLATION...
-
Page 24: W-8: Snmp Gateway Installation Worksheet
SNMP will check for trap expiration. For example, if the value is 60, every 60 seconds SNMP will check to remove any traps (as appropriate) from the active list. Enter a value in seconds. XEROX DOCUMENT SERVICES PLATFORM SERIES GETTING READY FOR THE DOCUSP INSTALLATION... - Page 25 DocuPrint 180 1.3.6.1.4.1.253.8.62.1.18.2.5.1 DocuPrint 100mx 1.3.6.1.4.1.253.8.62.1.18.2.8.1 DocuPrint 115mx 1.3.6.1.4.1.253.8.62.1.18.2.9.1 DocuPrint 135mx 1.3.6.1.4.1.253.8.62.1.18.2.17.1 DocuPrint 155mx 1.3.6.1.4.1.253.8.62.1.18.2.18.1 DocuPrint 180mx 1.3.6.1.4.1.253.8.62.1.18.2.19.1 DocuColor 2045 1.3.6.1.4.1.253.8.62.1.17.1.1.1 DocuColor 2060 1.3.6.1.4.1.253.8.62.1.17.2.1.1 DocuTech/DocuPrint 75 1.3.6.1.4.1.253.8.62.1.18.2.6.1 DocuTech/DocuPrint 90 1.3.6.1.4.1.253.8.62.1.18.2.7.1 XEROX DOCUMENT SERVICES PLATFORM SERIES GETTING READY FOR THE DOCUSP INSTALLATION...
-
Page 26: W-9: Client Workstations Worksheet
Use this worksheet to indicate both the type and the number of workstations your customer will be using to submit documents to the DocuSP controller. r Check here if your customer has contracted Xerox to install document submission software packages on their workstations. The Xerox service representative will reference this worksheet during the installation. - Page 27 DOCUSP 3.x W-9 data element definitions This section includes information the Xerox personnel use when document submission software is loaded onto additional customer workstations. The following document submission utilities are currently available: Xerox Client Submission (command line): Xerox Client Submission Software is a command line document submission utility available on Solaris 2.x systems only.
