- Page 1 2000WATT D IGITAL GENERATOR Distributed by: ALL-POWERAMERICA @2005 ALL-POWERAMERICA 16273 E. Gale Ave City Of Industry, California 91745 www.allpoweramerica.com...
-
Page 2: Table Of Contents
PREFACE CONTENTS Thank you for purchasing an ALL POWER AMERICA generator. 1. SAFETY INSTRUCTIONS ................This manual covers operation and maintenance of the 2000 watt digital generator. 2. SAFETY LABEL LOCATIONS ..............information in this publication is based the latest product information 3. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS 1. SAFETY iNSTRUCTiONS To ensure safe operation -- To ensure safe operation • Gasoline is extremely flammable and explosive under certain conditions. Refuel in a well ventilated area with the engine stopped. • Keep away from cigarette, smoke sparks when refueling... -
Page 4: Safety Label Locations
2. SAFETY LABEL LOCATIONS These lables warn you potential hazards that can cause serious injury. Read the labels and safety notes and precautions described in manual carefully. If a label is lost or becomes unreadable, contact your ALL POWER AMERICA dealer for a replacement. -
Page 5: Component
Control panel 3. COMPONENT IDENTIFICATION E type FUEL CAP VENTLEVER CHOKELEVER SMART-THROTTLE SWLTCH FUEL FILLER CAP OUTPUT INDICATOR LIGHT OVERLOAD iNDICATOR UGHT MAINTENANCE COVER CONTROL PANEL DC RECEPTACLE STARTER GRIP GROUND TERMINAL ENGINE SWITCH DC CIRCUIT PROTECTOR SPARK PLUG OiL ALERT INDICATOR LIGHT MAINTENANCE COVER... - Page 6 A type (120V) Austype Smart throttle Engine speed is kept at idle automatically when the electrical appliance is disconnected and it returns to the proper speed to power of the electrical load when electrical appliance is connected. This position is recommended to minimize the fuel consumption while in operation.
- Page 7 NOTE: The Oil Alert System will automatically stop the engine before the oil level falls 4. PRE-OPERAT(ON CHECK below the safe limit. However, to avoid the inconvenience of an unexpected shutdown, it is still advisable to visually inspect the oil level regularly. UPPER LEVEL OIL FILLER CAP 1.
- Page 8 Fuel tank capacity: 3.7 l iter 3.Check the aircleaner. Check the a ir c leaner element tobe sure itisclean and i ngood condition. FUEL FILLER Loosen the cover screw and r emove the l eft side maintenance cover. Press the l atch tab o n the t op o f t he air c leaner body, remove the air c leaner cover,...
-
Page 9: Starting The Engine
3. Move the choke lever to the START position. 5. STARTING THE ENGINE NOTE: Do not use the choke when the engine is warm or the air temperature is high. Before starting the engine, disconnect any load from the AC receptacle. 1 .Turn the fuel cap lever fully clockwise to the ON position. -
Page 10: High Altitude Operation
5Move the c hoke lever tothe RUN position after the e ngine warms High a ltitude operation high altitude, the standard carburetor air-fuel mixture will be excessively rich. CHO_ LEVER Performance will decrease, and fuel consumption will increase. High altitude performance can be improved by installing a smaller diameter main fuel jet in the carburetor and readjusting the pilot screws. -
Page 11: Generator
6. GENERATOR • Do not exceed the rated power. The total wattage of all appliances connected must be considered. Be sure to ground the generator when the connected equipment is grounded. • Do not exceed the current limit specified for any one receptacle. •... -
Page 12: Output And Overload Indicators
AC applications Output and Overload Indicators 1. S tart the e ngine and m ake sure t he o utput indicator light (green) flash. 2.Confirm that the a ppliance tobe used isswitched off, and p lug i nthe a ppliance. The output indicator light (green) will remain flash during normal operating conditions. -
Page 13: Dc Application
DC application The D C receptacle may be used for c harging 12 volt automotive-type batteries only. The zero l oad voltage is15V-30V. • The battery gives off explosive gases; keep spark, flames and cigarettes away. Provide adequate ventilation when charging. •... -
Page 14: Stopping The Engine
Oil alert system 7. STOPPING THE ENGINE The oil alert system is designed to prevent engine damage caused by an insufficient amount of oil in the crankcase. Before the oil level in the crankcase falls below a safe limit, the oil alert system will automatically shut down the engine(the engine switch will To stop the engine in an emergency, turn the engine switch to the OFF position. -
Page 15: Maintenance
The exhaust contains poisonous carbon monoxide gas. • Use genuine ALL POWER AMERICA parts or their equivalent. The use of placement parts which are not of equivalent quality may damage the generator. - Page 16 1. CHANGING 2. AIR CLEANER SERVICE A dirty air cleaner will restrict air flow to the carburetor. To prevent carburetor malfunc- tion, service the air cleaner regularly. Service more frequently when operating Drain the oil while the engine is still warm to assure rapid and complete draining. generator in extremely dirty areas.
-
Page 17: Spark Plug Service
3. SPARK PLUG SERVICE 5. Visually inspect the spark plug. Discard it if the insulator is cracked or chipped. RECOMMENTDEDSPARK PLUG: A7RTC Clean the spark plug with a wire brush if it is to be reused. 6. Measure the plug gap with a feeler gauge. To ensure proper engine operation, the spark plug must be properly gapped and free of The gap should be 0.6-0.7mm... - Page 18 Drain all gasoline from the fuel tank into an approved gasoline container. 9. TRANSPORTING STORAGE Turn the engine switch ON, and loosen the carburetor drain screw and drain the gasoline from the carburetor into a suitable container. With the drain screw loosened remove the spark plug cap, and pull the starter grip 3 To prevent fuel spillage when transporting or during temporary storage, the generator...
-
Page 19: Troubleshooting
Appliance does not operate: 10. TROUBLESHOOTING Is the output indicator light ON? 1 When the engine will not start: Refuel the fuel tank I Is there fuel in the tank? Take the generator to an Is the overload in- dicator light ON? authorized dealer. -
Page 20: Specifications
11. SPECiFiCATiONS 12. ELECTRICAL WIRING DIAGRAM SPECIFICATIONS Blue ,,_.)_, Graz rectifier Model 2000 Digital Generator Rated frequency (Hz) I Charging winding Rated voltage (V) 120/240 Blue Brow Blackn Rated current (A) 13.316.7 Yellow 5000 Rated speed (rpm) M.ain. Rated output (kVA) Max output (kVA) -'-'Red(__ DC output... -
Page 21: Light Kit
13. LIGHT KIT MOUNTING INSTRUCTIONS LIGHT Our Light kit is designed specifically for use on this Generator. Tools required: Phillips Screwdriver Fittings supplied: (1) Portable Digital Generator (2) Light Kit Assembly (3) Antiskid Round (4) Antiskid Round Stud (5) Left Mount Plate of Light Kit (6) Right Mount Plate of Light Kit...
