Summary of Contents for Windsor ROMBUS RMBS12
- Page 1 Operating Instructions (ENG) MODELS: RMBS12 BEFORE S/N12236 RMBS16 BEFORE S/N 16905 Read instructions before operating the machine. 980124 09/20/05...
- Page 2 Phone Number: _________________________________________________________________________________________ OVERVIEW The Windsor Rombus Carpet Maintainer is designed to maintain your carpet using the Rombus quick clean, quick dry carpet care system. The machine has two counter rotating brushes that help scrub chemical into the carpet. The chemical, Red Carpet Rombus Carpet Clean Chemical, encapsulates the dirt, allowing both to be vacuumed up once the chemical has dried.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Machine Data Log/Overview.......2 GROUP PARTS LIST Table of Contents ........3 Handle Group..........5-1 HOW TO USE THIS MANUAL Base - Motor Group........5-3 Base - Brush Group........5-5 Notes............5-7 How to use this Manual.......1-1 Warranty.............5-8 SAFETY Important Safety Instructions......2-1 Hazard Intensity Level. -
Page 4: How To Use This Manual
DESCRIPTION – column is a brief description of the part. Parts may be ordered from authorized Windsor SERIAL NO. FROM – column dealers. When placing an order for parts, the indicates the first machine the part machine model and machine serial number are number is applicable to. -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precaution must always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE. This machine is for commercial use. WARNING: To reduce the risk of fire, electric shock, or injury: Connect to a properly grounded outlet. -
Page 6: Hazard Intensity Level
Unless Operation Guide is Read and understood. In Flammable or Explosive areas. In areas with possible falling objects. WHEN SERVICING MACHINE: Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use Windsor approved replacement parts. ROMBUS 980124 07/02/03... -
Page 7: Grounding Instructions
GROUNDING INSTRUCTIONS THIS PRODUCT IS FOR COMMERCIAL USE ONLY. ELECTRICAL: In the USA this machine operates on a standard 15 amp 115V, 60 hz, A.C. power circuit . The amp, hertz, and voltage are listed on the data label found on each machine. Using voltages above or below those indicated on the data label will cause serious damage to the motors. -
Page 8: Technical Specifications
TECHNICAL SPECIFICATIONS ITEM DIMENSION/CAPACITY Electrical 115V Nominal Power 550W Rated Amperage 7 Amps Brush Width RMBS12 12 inches (30 cm) RMBS16 16 inches (40 cm) Brush RPM 600 RPM Wheels 3 inches (7.5 cm) non-marking grey Dimensions – Weight RMBS12 40 lbs. -
Page 9: How The Machine Works
HOW THE MACHINE WORKS Congratulations! You are now the proud owner of a Windsor Rombus Carpet Maintainer. The Windsor Rombus Carpet Maintainer is designed to maintain your carpet using the Rombus Quick Clean, Quick Dry Carpet Care System. By using the Rombus Carpet Maintainer... -
Page 10: Machine Operation
MACHINE OPERATION PRE-RUN MACHINE INSPECTION MACHINE SHUT-DOWN AND Perform a pre-run inspection to find possible STORAGE problems that could cause poor performance or lost time from breakdown. Check the rating plate 1. Depress the foot switch to power off to confirm voltage and frequency is the same as machine. -
Page 11: Maintenance
MAINTENANCE BRUSH CLEANING AND DAILY MAINTENANCE MAINTENANCE 1. Clean and inspect brushes. After each session or carpet cleaning, the brushes 2. Clean and inspect brush housing and and the brush housing should be cleaned. Before machine. cleaning or changing the brushes, always unplug the machine from the power supply. -
Page 12: Machine Troubleshooting
MACHINE TROUBLESHOOTING PROBLEM CAUSE SOLUTION No power to machine Dead electrical circuit Check building circuit breaker in fuse box breaker Faulty power cord Replace power cord Power switch failure Replace power switch Faulty circuit breaker Replace circuit breaker Internal wiring problem With machine unplugged, check for and correct, any loose wire connections. - Page 13 THIS PAGE LEFT BLANK INTENTIONALLY ROMBUS 980124 07/02/03...
- Page 14 HANDLE NOTE: The handle view is shown from the Rear. This is to help clarify how the components are attached to the handle asm. ROMBUS 980124 09/22/04...
- Page 15 HANDLE SERIAL NO. PART NO. DESCRIPTION NOTES: FROM RMBS HANDLE ASM CMPLT 01014 CABLE RESTRAINT NOT SHOWN 01004 HANDLE GRIPS 01008 CAP PLUG 01009 CAP SCREW 01007 UPPER CABLE HOLDER, LOCKED 01088 CAP SCREW 01011 LWR CABLE HLDR, GYRATORY 01012 GYRATORY CBL RTNR SPRING 01013 BALL BEARING...
-
Page 16: Base - Motor Group
BASE - MOTOR 26 27 ROMBUS 980124 12/18/03... - Page 17 BASE - MOTOR SERIAL NO. PART NO. DESCRIPTION NOTES: FROM 01042 BUTTON SCREWS 01026 RMBS12 MCHN COVER RMBS12 ONLY 01037 RMBS16 MCHN COVER RMBS16 ONLY 01070 CABLE 10M 01069 MOTOR CABLE 1M 01076 CABLE GLAND 01068 SWITCH LOCKING NUT 01067 SWITCH 01054 SCREW...
-
Page 18: Base - Brush Group
BASE - BRUSH (END HOUSING) ROMBUS 980124 02/19/04... - Page 19 BASE - BRUSH SERIAL NO. PART NO. QTY DESCRIPTION NOTES: FROM 01059 NYLON BRUSH SHFT HSNG 01060 BEARING 01031 CAP SCREW 01022 RMBS12 BRUSH SHAFT ASM RMBS12 ONLY 01033 RMBS16 BRUSH SHAFT ASM RMBS16 ONLY 01032 SPRING LOADED PIN 01029 RMBS12 SPLASH GUARD RMBS12 ONLY 01040...
-
Page 20: Notes
NOTES ROMBUS 980124 07/02/03...
