PACKAGE HEAT PUMP SPECIFICATIONS

COOLING
CAPACITY
HEATING
RATING
UNIT
ELECTRICAL
SPECIFICATION
COMPRESSOR
CONDENSER
FAN MOTOR
CONDENSER FAN
CONDENSER
COIL
EVAPORATOR
BLOWER
MOTOR
EVAPORATOR
BLOWER
EVAPORATOR
COIL
GENERAL
INFORMATION
(1)
Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
*
Calculated external filter size based on air velocity of 300 ft/min.
Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
Unit specifications are subject to change without notice. ALWAYS refer to the units serial plate for the most up-to-date general and electrical information.
IMPORTANT: While this data is presented as a guide, it is important to electrically connect the unit and properly size wires and fuses/circuit breakers
in accordance with the National Electrical Code and/or all local codes. Data shown is w/o electric heaters.
8
COOLING CAPACITY, BTUH
SEER / EER
BTU/h (47°)
BTU/h (17°)
HSPF
VOLTAGE (NAMEPLATE)
AMPS
MIN CIRCUIT AMPACITY
MAX OVERCURRENT PROTECTION
TYPE
RATED LOAD AMPS
LOCKED ROTOR AMPS
HORSEPOWER
RPM
FULL LOAD AMPS
LOCKED ROTOR AMPS
BLADE DIAMETER (INCHES)
NUMBER OF BLADES
FACE AREA (SQ. FT.)
NUMBER OF ROWS
FINS PER INCH
HORSEPOWER - NUMBER OF SPEEDS
FULL LOAD AMPS
LOCKED ROTOR AMPS
MOTOR SPEED TAP - COOLING X-13
RPM
DIAMETER X WIDTH (INCHES)
RATED SCFM COOLING
MAX EXTERNAL STATIC PRESS ("w.c.)
FACE AREA (SQ. FT.)
NUMBER OF ROWS
FINS PER INCH
FILTER SIZE *
DRAIN SIZE (INCHES)
EXPANSION DEVICE (ID/OD)
REFRIGERANT CHARGE R410A (OZS.)
POWER SUPPLY
CONDUIT KNOCKOUT SIZE (INCHES)
LOW VOLTAGE
CONDUIT KNOCKOUT SIZE (INCHES)
LO PRESSURE SWITCH
OPENS / CLOSES PSIG
HI PRESSURE SWITCH - OPENS PSIG
OPENS / CLOSES PSIG
SHIPPING WEIGHT (LBS.)
OPERATING WEIGHT (LBS.)
GPH13[24-36]M41AB
GPH1324M41*
24,000
13/11
23000
12600
7.7
208/230-60-1
15.8
19.0
(1 )
30
SCROLL
12.8
58.3
1/4
830
1.5
3
22/3
17.02
1
24
1/4 - 3
1.5
2.13
High
952
10 x 9
825
0.5
4.52
4
16
25 x 25 x 1
3/4"
0.057/0.045
110
3/4, 1, 1-1/4
1/2
22 / 50
660 / 420
405
395
GPH1330M41* GPH1336M41*
29,000 34600
13/10.8 13/10.9
28800 34200
17000 19000
7.7 7.7
208/230-60-1 208/230-60-1
19.0 21.3
23.0 25.4
35 40
SCROLL SCROLL
16.0 16.7
77 79
1/4 1/4
830 830
1.5 1.5
3 3
22/3 22/4
17.02 16.83
1 1
24 22
1/3 - 3 1/3 - 3
1.5 3.06
3.2 4.1
High High
869 910
10 x 9 10 x 9
1050 1150
0.5 0.5
4.52 4.52
4 4
16 14
25 x 25 x 1 25 x 25 x 1
3/4" 3/4"
0.070/0.055 0.071/0.057
115 135
3/4, 1, 1-1/4 3/4, 1, 1-1/4
1/2 1/2
22 / 50 22 / 50
660 / 420 660 / 420
410 435
400 425
