Monogram.
™
ZIR36ND–GE Monogram 36" Built-In All-Refrigerator
Side Panel or Filler Options (Not to scale)
Side panels must be used whenever the sides of
the refrigerator or freezer will be exposed.
1/4" Side Panels
Insert end of
side panel into trim.
Top View
Trim
Standard 4" high toekick or trim to fit.
Height may vary depending on application.
1/2" to 3/4" Side
Panels Recessed
front edge.
Top View
Standard 4" high toekick or trim to fit.
Height may vary depending on application.
Specification Created 8/00
23 9/16"
84"
2 9/16"
23 5/16"
84"
2 5/16"
1/2" to 3/4" Side
Panels Leading Edge
Flush with Cabinet
Front. The front or
leading edge must be
finished to match
cabinetry.
Top View
Standard 4" high toekick or trim to fit.
Height may vary depending on application.
For answers to your Monogram,
GE Profile Performance Series,
GE Profile
GE Answer Center
R
24 3/4"
84"
3 3/4"
®
™
™
or GE appliance questions, call
®
service, 800.626.2000.
Listed by
Underwriters
Laboratories
