TEC MA-516-100 SERIES Owner's Manual page 104

3. If an hour value of more than 23 or a minute value of more than 59 is set, it will not result in
an error but the data will not be processed into that hourly range.
4. To change the table of hourly ranges once set, partially or entirely, do the entire setting
operation over again.
5. To clear the hourly range table once set, operate in SET mode
7
Example)
Hourly Rane Table
up to 8:00
8:00 to 9:00
9:00 to 10:00
10:00 to 13:00
13:00 to 16:30
16:30 to 18:00
@/FOR 0
Key Operation
Control Lock: SET
7 @/FOR
8 #/NS
0 0
#/NS
9 0 0
1 0 0 0 #/NS
#/NS
0
1 3 0
#/NS
1 6 3 0
#/NS
1 8 0 0
AT/TL
- 100 -
MA-516-100 SERIES
#/NS AT/TL
EO1-11116
