- Page 1 IDE3510U2 IDE3510U2GB Instruction Manual IDE Hard Drive Enclosure 3.5” Black External USB 2.0 IDE Hard Drive Enclosure...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question.
-
Page 3: Table Of Contents
Table of Contents Introduction ..............1 Packaging Contents..............1 System Requirements ..............1 Front View ..................2 Rear View ..................2 Installation ............... 3 Hardware Installation ..............3 Driver Installation .................4 Verifying Installation ..............4 How to Use ..............4 Specifications ..............6 Technical Support ............7 Warranty Information ............ -
Page 4: Introduction
Introduction The IDE3510U2/GB USB 2.0 IDE Hard Drive Enclosure provides cost- effective external storage, letting you connect a 3.5” IDE hard drive to a computer through USB 2.0, perfect for extending the useful life of older IDE (ATA) hard drives. Packaging Contents •... -
Page 5: Front View
Front View Thumb screws Disk Activity Power Rear View Power connector connector Power Switch... -
Page 6: Installation
Installation WARNING: Hard drives require careful handling, especially when being transported. If you are not careful with your hard disk, lost data may result. Always handle your hard drive and storage device with caution. Hardware Installation Remove the 4 thumb screws from both sides of the enclosure (8 thumb screws in total) and remove the side panels. -
Page 7: Driver Installation
Driver Installation Windows 2000/XP/Vista/7, Mac OS X, Linux No driver installation is required for these operating systems, as this enclosure is natively supported, so the drivers are already installed. Verifying Installation Windows 2000/XP/Server 2003/Vista From the main desktop, right-click on “My Computer” (“Computer” in Vista), then select Manage. - Page 8 Select Disk Management, in the left pane. In the right pane, you should notice the new hard drive: Right-click on the Unallocated block, and select New Partition. This will launch the New Partition Wizard. Please follow the instruction provided by the Wizard, to partition the drive for use. Once the partition has been created, the drive installed within the hard drive enclosure will be recognized as a New Volume in Disk Management, as well as in My Computer:...
-
Page 9: Specifications
Specifications Bus Interface USB 2.0 1 x USB type B External Connectors 1 x Power Connector Chipset Initio INIC-151 LEDs Power, Activity Maximum Data Transfer Rate USB: 480Mb/s 3.5” ATA/66/100/133 hard drive Hard Drive Compatibility up to 750GB in capacity Power Adapter 12VDC, 2A, center positive Dimensions... -
Page 10: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or... - Page 11 StarTech.com has been making “hard-to-find easy” since 1985, providing high quality solutions to a diverse IT and A/V customer base that spans many channels, including government, education and industrial facilities to name just a few. We offer an unmatched selection of computer parts, cables, A/V products, KVM and Server...
