2.4 DESCRIPTION OF CONTROL TERMINALS

Terminals
23
32
33
34
35
36
37
52
70, 72

2.5 PROTECTIONS

2.5.1 Internal Protection Components

2.5.2 Internal Fuses

Converter Designation
6KCS3185-480
6KCS3280-480
6KCS3420-480
F1, F2, F3
6KCS3650-480
6KCS310H-480
6KCS315H-480
12
Function
Input of the precharge enable control
Output of the MLP static signal (low - active signal)
(Common) Ground of the MLP and ML static signals
Reference point for Power supply +24V
Power supply output +24V
Output of the ML signal (low - active signal)
Power supply of the ML and MLP signals
(Common) Ground of the precharge enable control
OK Relay
Converter
6KCS3185-480
6KCS3280-480
6KCS3420-480
6KCS3650-480
6KCS310H-480
6KCS315H-480
Fuses
16 A / 500 V
fast 6 x 32 mm
25 A / 500 V
fast 6 x 32 mm
——————— INSTRUCTION MANUAL ————————
GEH-6639
Designation Varistors
575 V / 220 J
V1, V2, V3
Ø 20 mm
Designation Fuses for
F4 Power supply protection
F5 +24V protection
Voltage, Current
(15 - 35V, 5 - 11mA)
(5 ... 35V, 20mA source)
-
-
(32V / 300mA max)
(5 ... 35V, 20mA max sink)
(35V max)
-
(max 250V, 1A – AC11)
cs020
cs025
Fuses
4 A, 250 V fast 6,3 x 32
1 A, 250 V slow 5 x 20
cs030
