Snow Blower Owner's Manual
This manual contains important safety instructions for the gasoline engine powered
READ SAFETY WARNINGS AND OPERATING INSTRUCTIONS CAREFULLY.
DO NOT RETURN THIS SNOW BLOWER TO THE
When you call the help-line you will need to have the following information:
Date of Purchase:
Location of Purchase:
Serial # - Snow Blower:
*Serial number is located on the engine block below the
starter.
snow blower models: 30SS, 36SS, 45SS
SAVE THIS MANUAL.
Need Help?
Parts, Service, and Technical Assistance call:
1-800-393-0668
Monday-Friday 8:00AM-5PM EST
_______________________
_______________________
_______________________
STORE!
Snow blower and engine life are
extended greatly by performing
frequent lubrications, oil changes
and regular maintenance. To
protect your investment perform
routine maintenance.
