Printing Guide

Loading trays

CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately. Keep all other trays

closed until needed.

Pull the tray completely out.

Note: Do not remove trays while a job prints or while Busy appears on the printer display. Doing so may cause a jam.

Squeeze, and then slide the width guide tab to the correct position for the size of the paper you are loading.

Printing Guide

Page 1 of 4

Table of Contents

Do you have a question about the MS610de and is the answer not in the manual?

Page 1: Loading Trays
Printing Guide Page 1 of 4 Printing Guide Loading trays CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each tray separately. Keep all other trays closed until needed. Pull the tray completely out. Note: Do not remove trays while a job prints or while Busy appears on the printer display. Doing so may cause a jam. Squeeze, and then slide the width guide tab to the correct position for the size of the paper you are loading.
Page 2 Printing Guide Page 2 of 4 Unlock the length guide. Squeeze, and then slide the length guide tab to the correct position for the size of the paper you are loading. Notes: • For some paper sizes like letter, legal, and A4, squeeze and slide the length guide tab backward to accommodate their length.
Page 3 Printing Guide Page 3 of 4 Flex the sheets back and forth to loosen them. Do not fold or crease the paper. Straighten the edges on a level surface. Load the paper stack. Notes: • Load with the printable side facedown when using recycled or preprinted paper. •...
Page 4: Setting The Paper Size And Type
Printing Guide Page 4 of 4 • Load letterhead facedown, with the top edge of the sheet toward the front of the tray. For two‑sided printing, load letterhead faceup with the bottom edge of the sheet toward the front of the tray. •...
