  • Page 1 Technical Information Operating Instructions GPS164xHS GPS164/AQ/xHS...
  • Page 2: Contact Information

    Contact Information Meinberg Funkuhren GmbH & Co. KG Lange Wand 9 D-31812 Bad Pyrmont Telefon: ++49 (0) 52 81 / 9309-0 Telefax: ++49 (0) 52 81 / 9309-30 Internet: http://www.meinberg.de Email: info@meinberg.de December 16th, 2009...
  • Page 3: Table Of Contents

    Table of contents Contact Information................2 Content of the USB stick ..............4 General information................5 Block diagram GPS164xHS..............6 GPS164xHS features................7 Time zone and daylight saving ..........7 Pulse outputs ................8 Asynchronous serial ports ............9 Time code outputs ..............9 Introduction ...............
  • Page 4: Content Of The Usb Stick

    Content of the USB stick Besides this manual, the provided USB stick includes a setup program for the monitor software GPSMON32. This utility can be used to configure Meinberg GPS receivers via their serial ports and display status information of the module.
  • Page 5: General Information

    General information The Meinberg satellite receiver clocks of the GPS164xHS series are available with several options. This manual describes the following models: . . . 2 . . 2 . . The vaiants differ in power supply and the type of DC-isolation of the programmable pulse outputs.
  • Page 6: Block Diagram Gps164Xhs

    Block diagram GPS164xHS...
  • Page 7: Gps164Xhs Features

    GPS164xHS features The GPS164xHS is designed for mounting on a DIN rail. The front panel integrates five LED indicators, a hidden push button, an eight-pole terminal block, theree DSUB- and three BNC-connectors. The receiver is connected to the antenna/conver- ter unit by a 50 Ω-coaxial cable with length up to 300 m (when using RG58 cable). It is possible to connect up to four receivers to one antenna by using an optional antenna diplexer.
  • Page 8: Pulse Outputs

    Pulse outputs The pulse generator of the satellite controlled clock GPS164xHS containes three independant channels and is able to generate a multitude of different pulses, which are configured with the software GPSMON32. The active state of each channel is invertible, the pulse duration settable between 10 msec and 10 sec in steps of 10 msec.
  • Page 9: Asynchronous Serial Ports

    (IRIG) in the early 60´s. Detailed information about IRIG and other time codes can be found on http://www.meinberg.de/english/info/irig.htm Except these time codes other formats, like NASA36, XR3 or 2137, are still in use. The module GPS164TDHS however generates IRIG-B or AFNOR NFS-500 only.
  • Page 10: Available Time Codes

    Available time codes The time code generator of the module GPS164xHS is able to generate the time- codes shown below. The modulated codes (IRIG B122/B123, AFNOR, IEEE1344) are available via the BNC-connector, the unmodulated codes (IRIG B002/B003 and IEEE1344) via a DSUB connector in the front panel. The unmodulated codes are available as a transistor output with internal pull up (470 Ω...
  • Page 11: Irig Standard Format

    IRIG standard format...
  • Page 12: Afnor Time Code Format

    AFNOR time code format...
  • Page 13: Assignment Of Cf Segment In Ieee1344 Mode

    Assignment of CF Segment in IEEE1344 mode i t i i f i i t i i f i i t r s f f s f f , ' + ' - ' s f f s f f s f f l l a s f f...
  • Page 14: Dcf77 Emulation

    DCF77 emulation The GPS164xHS satellite controlled clock generates time marks which are compati- ble with the time marks spread by the German long wave transmitter DCF77. If configured in GPSMON32, these time marks are available as pulse outputs. In addition, an AM-modulated carrier frequency of 77.5kHz is available via a BNC- connector in the front panel.
  • Page 15: Installation

    Installation Power supply The variants of the module GPS164xHS are designed for following power supply options: GPS164DHS GPS164/AQ/DHS: 19...72 VDC (DC-insulation 1.5 kVDC) GPS164AHS GPS164/AQ/AHS: 100...240 VAC, 47...63 Hz GPS164DAHS GPS164/AQ/DAHS : 100...240 VDC 100...240 VAC, 47...63 Hz The voltage feed of the DC variants is done via terminal blocks in the frontpanel of the clock and should have low resistance to minimize spurious emission (EMI).
  • Page 16: Mounting The Antenna

    Mounting the antenna The GPS satellites are not stationary but circle round the globe in a period of about 12 hours. They can only be received if no building is in the line-of-sight from the antenna to the satellite, so the antenna/converter unit must be installed in a location from which as much of the sky as possible can be seen.
  • Page 17: The Front Panel Layout

    The front panel layout FAIL LED The FAIL LED is turned on whenever the receiver is not synchronous to the GPS- system. Oc 1 Lock Oc 2 LOCK LED Fail Oc 3 The LOCK LED is turned on if the recei- TC_Out ver has acquired at least four satellites COM 0...
  • Page 18: Bnc Connector Dcf Out

    BNC connector DCF Out The insulated AM-modulated carrier frequency is available using this connector. Connectors TC_Out ( AM / DCLS ) The modulated IRIG or AFNOR ti mecode signal is output at the BNC connector TC_Out ( AM ), the un-modulated time code signal is available at Sub-D Connector TC_Out ( DCLS ) BNC connector GPS Ant The antenna/converter unit is connected to the receiver circuit of the GPS164xHS...
  • Page 19: Assignment Of The Dsub Connectors

    Assignment of the DSUB connectors The serial ports COM0 and COM1 as well as the unmodulated IRIG/AFNOR time code signals are accessible via nine-pole DSUB connectors in the frontpanel. These RS-232 interfaces can be connected to a computer by using a standard modem cable. TxD describes the sending, RxD the receiving line of the GPS164xHS.
  • Page 20: Technical Specifications Gps164Xhs

    Technical specifications GPS164xHS RECEIVER: 6 channel C/A code receiver with external antenna/converter unit ANTENNA: Antenna/converter unit with remote power supply refer to chapter "Technical specifications of antenna" ANTENNA INPUT: Antenna circuit dc-insulated; dielectric strength: 1000V Length of cable: refer to chapter "Mounting the antenna" TIME TO SYNCHRO- NIZATION: one minute with known receiver position and valid almanac...
  • Page 21 COM1 (RS-232, optional RS-485) Baud Rate: 300 up to 19200 Framing: 7N2, 7E1, 7E2, 8N1, 8N2, 8E1 time string selectable for COM0 and COM1 'standard Meinberg', 'SAT', 'Uni Erlangen (NTP)', 'NMEA-183' ( RMC ), and 'Computime' default settings: COM0: 19200, 8N1 COM1:...
  • Page 22 POWER REQUIREMENTS: GPS164DHS, GPS164/AQ/DHS 19...72 VDC DC-isolation 1.5 kVDC GPS164AHS, GPS164/AQ/AHS 100...240 VAC, 47...63 Hz fuse: 500 mA GPS164DAHS, GPS164/AQ/DAHS 100...240 VDC 100...240 VAC, 47...63 Hz fuse: 500 mA DIMENSION: GPS164DHS, GPS164/AQ/DHS 105 mm x 85 mm x 104 mm (height x width x depth) GPS164AHS, GPS164/AQ/AHS, GPS164DAHS,GPS164/AQ/DAHS...
  • Page 23: Front Views

    Front views The following figures are showing the front panels of the variants of the module GPS164xHS: Standard Option PhotoMOS relays...
  • Page 24: Technical Specifications Of Antenna

    Technical specifications of antenna ANTENNA: dielectrical patch antenna, 25 x 25mm receive frequency: 1575.42 MHz bandwidth: 9 MHz CONVERTER: local oscillator to converter frequency: 10 MHz first IF frequency: 35.4 MHz POWER REQUIREMENTS: 12V ... 18V, @ 100mA (provided via antenna cable) CONNECTOR: coax type N, female AMBIENT...
  • Page 25: Assembly With Cn-Ub/E (Cn-Ub-280Dc)

    Assembly with CN-UB/E (CN-UB-280DC)
  • Page 26: Format Of The Meinberg Standard Time String

    Format of the Meinberg standard time string The Meinberg standard time string is a sequence of 32 ASCII characters starting with the STX (start-of-text) character and ending with the ETX (end-of-text) character. The format is: <STX>D:dd.mm.yy;T:w;U:hh.mm.ss;uvxy<ETX> The letters printed in italics are replaced by ASCII numbers whereas the other characters are part of the time string.
  • Page 27: Format Of The Sat Time String

    Format of the SAT time string The SAT time string is a sequence of 29 ASCII characters starting with the STX (start-of-text) character and ending with the ETX (end-of-text) character. The format <STX>tt.mm.jj/w/hh.mm.ssMEzzxy<CR><LF><ETX> The letters printed in italics are replaced by ASCII numbers whereas the other characters are part of the time string.
  • Page 28: Format Of The Time String Uni Erlangen (Ntp)

    Format of the time string Uni Erlangen (NTP) The time string Uni Erlangen (NTP) of a GPS-clock is a sequence of 66 ASCII characters starting with the STX (start-of-text) character and ending with the ETX (end-of-text) character. The format is: <STX>tt.mm.jj;...
  • Page 29 leap second insertion ‘L’ leap second is actually inserted (active only in 60th sec.) ‘ ‘ (space, 20h) no leap second is inserted bbb.bbbb latitude of receiver position in degrees leading signs are replaced by a space character (20h) latitude, the following characters are possible: ‘N’...
  • Page 30: Format Of The Nmea (Rmc) String

    Format of the NMEA (RMC) string The NMEA String is a sequence of 65 ASCII characters starting with the ‘$’ character and ending with the characters CR (carriage return) and LF (line-feed). The format is: $GPRMC,hhmmss.ss,A,bbbb.bb,n,lllll.ll,e,0.0,0.0,ddmmyy,0.0,a*hh<CR><LF> The letters printed in italics are replaced by ASCII numbers or letters whereas the other characters are part of the time string.
  • Page 31: Format Of The Computime Time String

    Format of the Computime Time String The Computime time string is a sequence of 24 ASCII characters starting with the T character and ending with the LF (line feed, ASCII Code 0Ah) character. The format T:yy:mm:dd:ww:hh:mm:ss<CR><LF> The letters printed in italics are replaced by ASCII numbers whereas the other characters are part of the time string.
  • Page 32: The Program Gpsmon32

    The program GPSMON32 The program GPSMON32 can be used to monitor and program all essential functions of Meinberg GPS-Receivers. The Software is executable under Win9x/2k/ NT. To install GPSMON32 just run Setup.exe from the included diskette and follow the instructions of the setup program.
  • Page 33: Online Help

    Online Help The online help can be started by clicking the menu item 'Help' in menu Help. In every program window a direct access to a related help topic can be obtained by pressing F1. The help language can be selected by clicking the menu items Deutsch/ Englisch in the Help Menu.
