  • Page 1 Technical Information Operating Instructions GPS169PCI with IRIG-Generator...
  • Page 2: Impressum

    Impressum Meinberg Funkuhren GmbH & Co. KG Auf der Landwehr 22 D-31812 Bad Pyrmont Phone: ++49 52 81 - 9309-0 Fax: ++49 52 81 - 9309-30 Internet: http://www.meinberg.de Email: info@meinberg.de February 20, 2006...
  • Page 3: Table Of Contents

    Table of Contents Impressum .................... 2 Driver Diskette ..................4 Content of the diskette ................5 General information ................6 Block diagram GPS169PCI ..............7 GPS169PCI features ................8 Time zone and daylight saving ............ 8 Asynchronous serial ports ............9 Time capture inputs ..............
  • Page 4: Driver Diskette

    Technical specifications of antenna ........... 24 Assembly with CN-UB/E (CN-UB-280DC) ......25 Time strings ................26 Format of the Meinberg Standard time string ....26 Format of the Meinberg Capture String ......27 Format of the SAT-time string ......... 28 Format of the NMEA 0183 string (RMC) .......
  • Page 5: Content Of The Diskette

    Execute Setup.exe and choose the installation directory. By default, the installation directory is: C:\Program Files\Meinberg\MbgMon Then shut down the computer, install the Meinberg radio clock plug-in board into a free slot and reboot. Now you are asked to install a driver. The driver file MEINBERG.INF can be found in the subdirectory Driver\PnP...
  • Page 6: General Information

    General information The satellite clocks made by Meinberg have been designed to provide extremly precise time to their users. The clocks have been developed for applications where conventional radio clocks can´t meet the growing requirements in precision. High precision available 24 hours a day around the whole world is the main feature of the new system which receives its information from the satellites of the Global Posi- tioning System.
  • Page 7: Block Diagram Gps169Pci

    Block diagram GPS169PCI...
  • Page 8: Gps169Pci Features

    250m. Power is supplied to the unit DC insulated across the antenna cable. Optionally, an overvoltage protection and an antenna distributor are available. The antenna distributor can be used to operate up to 4 Meinberg GPS receivers using a single antenna/converter unit.
  • Page 9: Asynchronous Serial Ports

    Asynchronous serial ports Two asynchronous serial interfaces (RS232) called COM0 and COM1 are available to the user. Only COM0 is available at the rear panel slot cover, COM1 must use another submin-D connector which can optionally be connected to the 5 pin jumper block on the board.
  • Page 10: Dcf77 Emulation

    DCF77 emulation The GPS169PCI satellite clock generates TTL level time marks (active HIGH) which are compatible with the time marks spread by the German long wave transmitter DCF77. This long wave transmitter installed in Mainflingen near Frankfurt/Germany transmits the reference time of the Federal Republic of Germany: time of day, date of month and day of week in BCD coded second pulses.
  • Page 11: Connectors And Leds In The Rear Slot Cover

    This port can not be used as serial port for the compu- ter. Instead, it can be uses to send out Meinberg's standard time string to an external device. A DIL switch on the board can be used to wire some TTL inputs or outputs (0..5V) to some connector pins.
  • Page 12: Installing The Radio Clock

    Installing the radio clock Every PCI board is a plug&play board. After power-up, the computer's BIOS assigns ressources like I/O ports and interrupt lines to the board, the user does not need to take care of the assignments. The programs shipped with the board retrieve the settings from the BIOS.
  • Page 13: Mounting The Antenna

    Mounting the antenna The GPS satellites are not stationary but circle round the globe in a period of about 12 hours. They can only be received if no building is in the line-of-sight from the antenna to the satellite, so the antenna/converter unit must be installed in a location from which as much of the sky as possible can be seen.
  • Page 14: Firmware Updates

    the new almanac is complete and the system switches to Warm Boot mode scanning for other satellites. In the default mode of operation, neither pulse outputs nor the serial ports will be enabled after power-up until synchronization has been achieved. However, it is possible to configure some or all of those outputs to be enabled immediately after power-up.
  • Page 15: Replacing The Lithium Battery

    Replacing the lithium battery The life time of the lithium battery on the board is at least 10 years. If the need arises to replace the battery, the following should be noted: ATTENTION! Danger of explosion in case of inadequate replacement of the lithium battery.
  • Page 16: Timecodes

    Timecodes The transmission of coded timing signals began to take on widespread importance in the early 1950´s. Especially the US missile and space programs were the forces behind the development of these time codes, which were used for the correlation of data.
  • Page 17: Irig Standard Format

    IRIG standard format...
  • Page 18: Afnor-Standard Format

    AFNOR-standard format...
  • Page 19: Assignment Of Cf Segment In Ieee1344 Mode

    Assignment of CF Segment in IEEE1344 mode i t i i f i i t i i f i i t r s f f s f f , ' + ' - ' s f f s f f s f f l l a s f f...
  • Page 20: Generated Timecodes

    Generated timecodes The board GPS169PCI generates modulated unmodulated (TTL into 50 Ω) time- codes, so that six different signals are available: a) B002: 100pps, DC-signal, no carrier BCD time of year b) B122: 100pps, AM-sinewave signal, 1 kHz BCD time of year c) B003: 100pps, DC-signal, no carrier BCD time of year, SBS time of day...
  • Page 21: Technical Specifications Gps169Pci

    Technical Specifications GPS169PCI RECEIVER: Six channel C/A code receiver with external antenna/converter unit ANTENNA: Antenna/converter unit with remote power supply refer to chapter "Technical specifications of antenna" ANTENNA INPUT: Antenna circuit dc-insulated; dielectric strength: 1000V Length of cable: refer to chapter "Mounting the Antenna" TIME TO SYNCHRO- NIZATION: one minute with known receiver position and valid almanac...
  • Page 22 TTL into 50 Ω, active-high or -low, selected by jumper SERIAL PORTS: 2 asynchronous serial ports (RS-232) Baud Rate: 300 up to 19200 Framing: 7N2, 7E1, 7E2, 8N1, 8N2, 8E1 default setting: COM0: 19200, 8N1 Meinberg Standard time string, per second COM1: 9600, 8N1 Capture string, automatically...
  • Page 23: Assignment Of The 5 Pin Jumper Block

    POWER REQUIREMENTS: 5V ± 5%, @250mA 12V ± 5%, @190mA -12V ± 5%, @10mA delivered by PCI bus RF CONNECTOR: female coaxial BNC-connectors for antenna and modulated timecode AMBIENT TEMPERATURE: 0 ... 60°C HUMIDITY: 85% max. Assignment of the 5 pin jumper block The jumper block can be used to access the 10 MHz frequency output and the serial port COM1.
  • Page 24: Technical Specifications Of Antenna

    Technical specifications of antenna ANTENNA: dielectrical patch antenna, 25 x 25mm receive frequency: 1575.42 MHz bandwidth: 9 MHz CONVERTER: local oscillator to converter frequency: 10 MHz first IF frequency: 35.4 MHz POWER REQUIREMENTS: 12V ... 18V, @ 100mA (provided via antenna cable) CONNECTOR: coax type N, female AMBIENT...
  • Page 25: Assembly With Cn-Ub/E (Cn-Ub-280Dc)

    Assembly with CN-UB/E (CN-UB-280DC)
  • Page 26: Time Strings

    Time strings Format of the Meinberg Standard time string The Meinberg Standard time string is a sequence of 32 ASCII characters starting with the STX (start-of-text) character and ending with the ETX (end-of-text) charac- ter. The format is: <STX>D:dd.mm.yy;T:w;U:hh.mm.ss;uvxy<ETX> The letters printed in italics are replaced by ASCII numbers whereas the other charac- ters are part of the time string.
  • Page 27: Format Of The Meinberg Capture String

    Format of the Meinberg Capture String The Meinberg Capture string is a sequence of 31 ASCII characters terminated by a CR/LF (Carriage Return/Line Feed) combination. The format is: CHx_tt.mm.jj_hh:mm:ss.fffffff<CR><LF> The letters printed in italics are replaced by ASCII numbers whereas the other charac- ters are part of the time string.
  • Page 28: Format Of The Sat-Time String

    Format of the SAT-time string The SAT-time string is a sequence of 29 ASCII characters starting with the STX (start-of-text) character and ending with the ETX (end-of-text) character. The format <STX>dd.mm.yy/w/hh.mm.ssxxxxuv<ETX> The letters printed in italics are replaced by ASCII numbers whereas the other charac- ters are part of the time string.
  • Page 29: Format Of The Nmea 0183 String (Rmc)

    Format of the NMEA 0183 string (RMC) The NMEA string is a sequence of 65 ASCII characters starting with the ‘$’ character and ending with the characters CR (carriage return) and LF (line-feed). The format is: $GPRMC,hhmmss.ss,A,bbbb.bb,n,lllll.ll,e,0.0,0.0,ddmmyy,0.0,a*hh<CR><LF> The letters printed in italics are replaced by ASCII numbers or letters whereas the other characters are part of the time string.
  • Page 30: Format Of The Uni Erlangen String (Ntp)

    Format of the Uni Erlangen string (NTP) The time string Uni Erlangen (NTP) of a GPS-clock is a sequence of 68 ASCII characters starting with the STX (start-of-text) character and ending with the ETX (end-of-text) character. The format is: <STX>tt.mm.jj; w; hh:mm:ss; voo:oo; acdfg i; bbb.bbbbn llll.lllle hhhhm<ETX> The letters printed in italics are replaced by ASCII numbers whereas the other charac- ters are part of the time string.
  • Page 31 leap second insertion ‘L’ leap second is actually inserted (active only in 60th sec.) ‘ ‘ (space, 20h) no leap second is inserted bbb.bbbb latitude of receiver position in degrees leading signs are replaced by a space character (20h) latitude, the following characters are possible: ‘N’...
  • Page 32: Format Of The Abb Spa Time String

    Format of the ABB SPA time string The ABB SPA time string is a sequence of 32 ASCII characters starting with the characters ">900WD" and ending with the <CR> (Carriage Return) character. The format is: >900WD:yy-mm-tt_hh.mm;ss.fff:cc<CR> The letters printed in italics are replaced by ASCII numbers whereas the other charac- ters are part of the time string.
