ECG050/0698
. .
. .
multiprocessing (SMP) configurations, a maximum of 512K L2 cache, and have a 512-MB memory
. .
cacheability limit.
. .
. .
. . Deschutes is the code name for a new family of processors that have increased bus speed and other
. .
enhancements. Intel is releasing several new Deschutes processors in 1998. Intel has announced
. .
the first of the new Deschutes-based processors
. .
. .
The Deschutes Pentium II processors are based on sixth-generation core logic and industry-
. .
. . standard 32-bit Intel Architecture (IA32). The Deschutes Pentium II processors are packaged in the
. .
same Slot 1 form factor as older Klamath Pentium II processors, but are not a drop-in replacement
. .
. . for Klamath Pentium II processors in most cases. Compared with Klamath Pentium II processors,
. .
Deschutes Pentium II processors have increased speed, expanded system memory support, and
. .
. .
other enhancements, but they still do not support greater than 2P SMP.
. .
. .
Intel has also pre-announced some of the details of a second type of Deschutes processor, called the
. .
Pentium II Xeon. Although the Pentium II Xeon carries the Pentium II brand name, the Pentium II
. .
. .
Xeon differs significantly from both older Klamath Pentium II processors and the newer Deschutes
. .
Pentium II processors. The Pentium II Xeon processor will be packaged in a new, larger cartridge-
. .
. .
style package, and it will have a greatly enhanced level 2 (L2) cache subsystem. The Pentium II
. .
Xeon will also support four processor (or greater) SMP configurations. The Pentium II Xeon will
. .
. .
become the main processor for high-end products after its announcement in the middle of 1998.
. .
. .
In late 1999, Intel plans to launch a 64-bit (IA64) processor code-named Merced. Merced,
. .
. .
however, will not mark the end of the IA32 processor line. Intel plans to continue the IA32
. .
architecture concurrently with the Merced line.
. .
. .
. . The following two sections summarize the current details of the new Deschutes Pentium II and
. .
Pentium II Xeon processors.
. .
. .
. .
D P
. .
E S C H U T E S E N T I U M
. .
. .
Understanding the feature set of a Deschutes Pentium II processor can be confusing because Intel
. .
. . has introduced several Pentium II processors that have some, but not all, of the attributes of a full-
. .
featured Deschutes Pentium II processor
. .
. . following attributes:
. .
. .
Pentium II processor core technology (IA32)
. .
. .
Processor speeds of 350-, 400-, and 450-MHz
. .
. .
100-MHz GTL+ system bus
. .
. .
. .
Slot 1 cartridge
. .
. .
4 GB of cacheable memory space
. .
. .
MMX technology
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. . 1
In January 1998, Intel announced a 333-MHz Pentium II processor. This processor has the
. .
Deschutes logic core but retains all the other features of the Klamath Pentium II introduced in May
. .
. .
1997, such as a 66-MHz GTL+ bus and 512-MB system memory limit. In 2Q 1998, Intel
. .
announced a 333-MHz Deschutes Pentium II processor that still has the 66-MHz GTL+ bus but
. .
. .
extends support for up to 4 GB of system memory.
. .
.

(cont.)
350 MHz and 400 MHz Pentium II processors.
I I
1
. A full-featured Deschutes Pentium II processor has the
