Record All Information and attach sales
receipt here for future reference:
Purchase Date:__________________________
Serial #: ________________________________
Questions? 1-800-888-2468
Learn more about your pressure washer,
get answers to frequently asked questions,
and register on line at
www.excellpressurewasher.com
Table of Contents
Safety Guidelines/Definitions.................. 2
Consumer Saftey Information ................ 2
Important Safety Instructions ..............2-7
Specifications .......................................... 7
Carton Contents ...................................... 8
Assembly Instructions ....................... 8-10
Operating Instructions .................... 10-15
Please make certain that the person who is to use this equipment carefully
reads and understands these instructions before operating.
Pressure Washer
Operation Manual
Maintenance .................................... 15-16
Storage ............................................ 16-17
Accessories ...........................................17
Repairs ...................................................18
Trouble Shooting Guide .................. 18-19
Français ........................................... 21-40
Español ............................................ 41-61
IMPORTANT
Part No.
for model XR2625
A14687
Rev. 0 1/4/06
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Excell XR2625
Summary of Contents for Excell XR2625
-
Page 1: Table Of Contents
Pressure Washer Record All Information and attach sales Operation Manual receipt here for future reference: for model XR2625 Purchase Date:__________________________ Serial #: ________________________________ Questions? 1-800-888-2468 Learn more about your pressure washer, get answers to frequently asked questions, and register on line at www.excellpressurewasher.com Table of Contents Maintenance ........ -
Page 2: Safety Guidelines/Definitions
SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these symbols. - Page 3 RISK OF EXPLOSION OR FIRE (CONTINUED) WHAT CAN HAPPEN HOW TO PREVENT IT • Operating the pressure washer in an • Operate and fuel equipment in ex plo sive en viron ment could re sult well-ven ti lat ed areas free from in a fire.
- Page 4 RISK OF FLUID INJECTION AND LACERATION WHAT CAN HAPPEN HOW TO PREVENT IT • Your pressure washer operates at • Inspect the high-pressure hose fluid pressures and velocities high regularly. Replace the hose enough to penetrate human and immediately if it is damaged, animal flesh, which could result in worn, has melted from contacting amputation or other serious injury.
- Page 5 RISK OF UNSAFE OPERATION WHAT CAN HAPPEN HOW TO PREVENT IT • Unsafe op er a tion of your pressure • Do not use chlorine bleach or any wash er could lead to se ri ous in ju ry other corrosive compound. or death to you or others.
- Page 6 RISK OF INJURY OR PROP ER TY DAMAGE WHEN TRANSPORTING OR STORING WHAT CAN HAPPEN HOW TO PREVENT IT • Fuel or oil can leak or spill and could • If pressure washer is equipped with result in fire or breathing hazard. Se ri- a fuel shut-off valve, turn the valve to ous in ju ry or death can re sult.
-
Page 7: Specifications
RISK OF CHEMICAL BURN WHAT CAN HAPPEN HOW TO PREVENT IT • Use of acids, toxic or cor ro sive • Do not use ac ids, gasoline, ker- chemicals, poisons, in sec ti cides, or o sene, or any other flammable any kind of flam ma ble solvent with materials in this product. -
Page 8: Carton Contents
CARTON CONTENTS Operation Manual Chemical Screws Hose Knobs "J" Bolts Engine Frame and Engine Wheel Assembly Manual Cleaning Tool Bagged Parts Spray Gun Accessory Gatling Spray Wand Panel Assembly High Pressure Handle Storage Panel Hose Cover ASSEMBLY INSTRUCTIONS Locate and remove all loose parts from the carton. - Page 9 Assemble a "J" bolt through frame as shown (both side). Align tabs on accessory storage panel cover with holes in accessory storage panel and slide Slide handle onto "J" bolts and down until it locks into place. attach with knobs (both sides) . Tighten securely.
-
Page 10: Operating Instructions
Risk of bursting. 12. Attach high pressure hose to gun. Use a tire pressure gauge to check the tires pressure before each use and while infl ating tires; see the tire sidewall for the correct tire pressure. NOTE: Air tanks, compressors and similar equipment used to infl... -
Page 11: Basic Elements Of A Pressure Washer
BASIC ELEMENTS OF A Allowing the unit to run for more than PRESSURE WASHER two minutes without the gun trigger High Pressure Pump (located inside pulled could cause overheating and the shroud, not shown): Increases damage to the pump. the pressure of the water supply. Chemical Injection System: Mixes Engine: Drives the high pressure cleaners or cleaning solvents with... - Page 12 Risk of fl uid injection. Do Not attempt to change nozzles while pressure washer is running. Turn engine off before changing nozzles. Press turret release button to release turret. Rotate turret to chosen nozzle. Push turret onto nozzle and lock into place.
- Page 13 NOTE: Chemicals and soaps will not siphon when spray wand is in the high pressure setting. TO EASILY REMOVE HOSE Remove the accessory storage panel cover. Remove hose from hose reel and replace accessory storage panel cover. To reduce the risk of injury, read the pressure washer instruction manual and the engine instruction manual before starting pressure washer.
- Page 14 STARTING If applying a chemical or cleaning solution, see How Prior to starting, refer to your engine To Apply Chemicals/Cleaning manual for proper starting procedure. Solvents instructions in this In a well ventilated outdoor section. area add fresh, high quality, Turn water source on.
-
Page 15: Maintenance
Risk of property SHUTTING DOWN damage. NEVER After each use, if you have applied turn the water off with the engine chemicals, place chemical hose running. into container of clean water and Turn water source off. draw clean water through chemical Pull trigger on spray gun to relieve injection system to rinse system any water pressure in hose or spray... -
Page 16: Storage
HOW TO CLEAN THE WATER Clean fi lter by fl ushing it with water on both sides. INLET FILTER Re-insert fi lter into water inlet of This screen fi lter should be checked pump. NOTE: Cone side faces out. periodically and cleaned if necessary. NOTE: Do not operate pressure Remove Filter Screen... -
Page 17: Accessories
Fold the handle as shown. PRESSURE WASHER Drain all water from high pressure hose and disconnect from pump outlet. Drain all water from spray gun and wand by holding spray gun in a vertical position with nozzle end pointing down and squeezing trigger. -
Page 18: Repairs
REPAIRS To assure product SAFETY and RELIABILITY, repairs, maintenance and adjustment should be performed by an Authorized Warranty Service Center. Always use identical replacement parts. For the location of the nearest Authorized Warranty Service Center call 1-800-888-2468 or visit our website www. excellpressurewasher.com. TROUBLE SHOOTING GUIDE CAUSE CORRECTION... - Page 19 PROBLEM CAUSE CORRECTION Will not draw See How to Use Spray Wand Spray wand not in low pressure. chemicals paragraph in the Operation Section. Chemical filter clogged. Clean filter. Make sure end of chemical hose Chemical screen not in cleaning is fully submerged into cleaning solution.
-
Page 20: Limited Warranty
LIMITED WARRANTY ONE YEAR LIMITED WARRANTY ON PRODUCT COMPONENTS EXCLUDING IC2 PUMP Black & Decker (U.S.) Inc. warrants to the original purchaser that the frame, wheels, gun, hose, wand, spray nozzle(s) and other components (excluding the IC2 pump) of the Excell pressure washers covered under this warranty are free from defects in material and workmanship for one year from the date of purchase.
