User's Guide
L601 / L602 / L603 / L604 / L605
L601M / L602M / L603M / L604M / L605M
DECT 6.0 Digital Cordless Phone
Warning
Use only the adapter and telephone line cord provided
in the box.

Advertisement

Table of Contents

   Also See for Motorola L601

   Related Manuals for Motorola L601

   Summary of Contents for Motorola L601

  • Page 1 User’s Guide L601 / L602 / L603 / L604 / L605 L601M / L602M / L603M / L604M / L605M DECT 6.0 Digital Cordless Phone Warning Use only the adapter and telephone line cord provided in the box.
  • Page 2 Motorola Phone! Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage.
  • Page 3 This User's Guide provides you with all the information you need to get the most from your phone. Before you make your first call you will need to set up your phone. Follow the simple instructions in 'Getting Started', on the next few pages.
  • Page 4: Table Of Contents

    1. Getting started ..........6 3.10 Storing a phonebook entry as a one touch number ..........14 1.1 Connecting the base........... 7 3.11 Dialing from the phonebook ......15 1.2 Installing and charging the handset 3.12 Caller ID ............15 battery pack ............7 3.12.1 Calls List ..........15 1.3 Assembling the rubber band of cordless handset (Not applicable for L60xM models) ..
  • Page 5 3.18 Registration ............20 3.18.1 Registering a handset ......20 3.19 Resetting all settings .........21 3.20 Paging/Finding a handset........21 4. Help..............21 5. General information ........23...
  • Page 6: Getting Started

    1. Getting started HANDSET RANGE Optimal range is reached when there are no other electrical WARNING appliances working within the range area. Any obstruction Do not place your phone in the bathroom or other humid between the base and handset will also reduce the range areas.
  • Page 7: Connecting The Base

    Connecting the base Installing and charging the handset battery pack 1. Plug the power adapter and the telephone line cord into the base. The power adapter with the larger pin is for the charger (only in multi-handset packs). 2. Plug the other end of the power adapter into a power outlet and the telephone line cord into a telephone wall jack.
  • Page 8: Assembling The Rubber Band Of Cordless Handset (not Applicable For L60xm Models)

    2. Slide the battery compartment cover back on. 2. Press and smooth out the rubber band to enwrap the 3. Put the handset on the base to charge for at least 24 handset firmly. hours. Once charged, the will indicate that the handset is fully charged.
  • Page 9: Setting The Date And Time

    Setting the date and time 2. Getting to know your phone 1. Press MENU and then VOL+ or REDIAL/VOL- to select Overview of your handset DATE&TIME . If you're a subscriber to your network's Caller ID service, the date and time is automatically set when a call is received.
  • Page 10 Get acquainted with the following 14 buttons on your Talk off / Back a) In menu / editing mode: Press to exit to previous level. handset and their multi-function tasks. b) In pre-dial mode / phonebook / calls list / redial list Scroll up / Volume up entry: Press to exit to idle.
  • Page 11 Speaker 12 Talk On / Flash a) In idle / pre-dial mode: Press to make a call with the a) In idle / pre-dial mode: Press to make a call. speakerphone. b) Calls List / phonebook / redial list entry: Press to make b) During a call: Press to toggle between the speakerphone a call to the selected entry.
  • Page 12 Cordless Handset LCD Display On when a call is muted. Full battery power level. 2/3 battery power level. 1/3 battery power level. Flashes when low battery level is detected, needs charging. Animation in cycle. Battery is charging. Display Icons In idle mode, the current time is displayed. On when speakerphone is turned on.
  • Page 13: Using The Phone

    Overview of the base 3. Using the phone Making a call 1. Enter the phone number and then press /FLASH or /SPEAKER to dial the phone number. Speed dial calling 1. In idle mode, press and hold a key from /1 to WXYZ/9 until the number is displayed and dialed.
  • Page 14: Muting A Call

    Muting a call Adding an entry to the phonebook 1. During a call, press MUTE to mute the microphone, so 1. Press that you can talk to someone else in the room without 2. Press MENU and then VOL+ or REDIAL/VOL- to scroll your caller hearing you.
  • Page 15: Dialing From The Phonebook

    3.11 Dialing from the phonebook • Information about incoming calls will vary by country and network operator. Some operators may charge a 1. Press and then VOL+ or REDIAL/VOL- to scroll subscription for their Caller ID service. and select the entry you want to dial. 3.12.1 Calls List 2.
  • Page 16: Viewing The Calls List

    3.12.2 Viewing the calls list 3.12.3 Saving a number from the calls list to the phonebook 1. Press CID to enter the calls list. 1. Press CID to enter the calls list. 2. Scroll VOL+ or REDIAL/VOL- to browse the calls list. 2.
  • Page 17: Personal Settings

    3.13 Personal Settings Menu map MAIN MENU DATE & TIME PHONEBOOK SETUP HS SETUP BS RESET SETTINGS SUB MENU YEAR VIEW RINGER TONE DIAL MODE CLR VOICE MAIL DATE RINGER VOLUME FLASH TIME ALL SETTINGS TIME EDIT KEY TONE AREA CODE DELETE LOW BATT TONE DELETE ALL...
  • Page 18: Intercom

    3.14.1 Calling another handset 1. Press MENU. 2. Press VOL+ or REDIAL/VOL- to scroll through the 1. Press INT. Except for the originating handset, all menu. registered handsets will be displayed in the list. 3. Press MENU for opening sub-menus and/or saving. 2.
  • Page 19: Three-party Conference Call

    3.15 Setting the dial mode 4. When the other handset answers by pressing /FLASH /SPEAKER, press /BACK to transfer the The default dialing mode is suitable for your country and call. If the other handset does not answer, press MUTE network operator.
  • Page 20: Setting The Area Code

    2. Press MENU and then VOL+ or REDIAL/VOL- to select To register an additional handset, FLASH TIME 1. Press MENU and then VOL+ or REDIAL/VOL- to select 3. Press MENU and then VOL+ or REDIAL/VOL- to the SETUP HS flash time you want. (8 options are available : 2.
  • Page 21: Resetting All Settings

    3.19 Resetting all settings 4. Help 1. Press MENU and then VOL+ or REDIAL/VOL- to select icon is not scrolling when the handset is RESET SETTINGS placed on the base 2. Press MENU and then VOL+ or REDIAL/VOL- to select •...
  • Page 22 No ring tone If the handset disconnects from the base during a • The ringer may be off. phone call • Check that the power cord is connected properly into the • The volume may need to be increased. base. Caller ID does not work •...
  • Page 23: General Information

    1. Read this User's Guide. 6. Unplug this product from the electrical outlet before 2. Visit our website: www.motorola.com cleaning. Do not use liquid cleaners or aerosol cleaners. 3. Contact Customer Service in the US and Canada at Use a damp cloth for cleaning.
  • Page 24: Installation Guidelines

    Unplug this cordless phone immediately 5. Do not place this product on an unstable cart, stand, or table. This product may fall, causing serious damage to from an outlet if: the product. • The power cord or plug is damaged or frayed. 6.
  • Page 25: Battery Safety Instructions

    Limited Warranty ("Warranty") • Do not burn, disassemble, mutilate, or puncture the battery. The battery contains toxic materials that could be Thank you for purchasing this Motorola branded product released, resulting in injury. manufactured under license by Binatone Electronics CAUTION International LTD ("BINATONE").
  • Page 26 THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL vary from one jurisdiction to another. OTHER WARRANTIES, EXPRESS OF IMPLIED. IN NO EVENT SHALL MOTOROLA OR BINATONE BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING General information...
  • Page 27 (d) other acts which are not the fault of purchaser of the product. MOTOROLA or BINATONE., are excluded from coverage. Consumer Products and The balance of the original Use of Non-Motorola branded Products and...
  • Page 28 (c) mismatched board serial numbers; or (d) (e) your address and telephone number. nonconforming or non-Motorola branded housings, or parts, These terms and conditions constitute the complete are excluded from coverage.
  • Page 29 radio frequency energy and, if not installed and used in not cause harmful interference, and (2) this device must accordance with the instructions, may cause harmful accept any interference received, including interference that interference to radio communications. However, there is no may cause undesired operation.
  • Page 30 AAAEQ##TXXXX. This identifier must be provided to your your telephone line, ensure the connection of this equipment local telephone company upon request. does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult The plug and jack used to connect this equipment to your telephone company or a qualified installer.
  • Page 31 Industry Canada If this product is equipped with a corded or cordless handset, Operation is subject to the following two conditions: (1) this it is hearing aid compatible. device may not cause harmful interference, and (2) this If this product has memory dialing locations, you may device must accept any interference, including interference choose to store emergency telephone numbers (e.g., police, that may cause undesired operation.
  • Page 32 Technical Specifications RF frequency band 1921.536 MHz - 1928.448 MHz Channels Operating 5ºC to 45ºC temperature Telephone base 96 — 130 Vms voltage (AC voltage, 60Hz) Telephone base 6VDC, 300 mA voltage (Adapter output) Handset voltage 2.4V 500mAh Ni-MH battery pack Charger voltage 6VAC, 300mA (Adapter output)
  • Page 33 Manufactured, distributed or sold by Binatone Electronics International LTD., official licensee for this product. MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. and are used under license. All other trademarks are the property of their respective owners.
