Camera Diagrams
BL-C101
Front View
A
Indicator
B
Lens
C
Microphone
A
B
C
*1
See 1.1 Understanding the Camera Indicator in the Troubleshooting Guide on the CD-ROM for indicator meaning.
Connections
Connect the camera to your router and to the power outlet as described below.
• Before proceeding, confirm that your PC is connected to your router and can access the Internet. Also confirm that your router's UPnP
enabled. (Most routers have UPnP
Camera website (http://panasonic.net/pcc/support/netwkcam/) for more information.
BL-C101
• Use a LAN cable that is no more than 30 m (98 feet 5 inches) long to connect the camera and the power transfer unit.
1
Connect the LAN cable to the
camera and the power transfer
unit.
2
Connect the LAN cable to the
router and the power transfer unit.
BL-C121
WIRELESS/WIRED switch
Router
WAN
LAN
4
Internet
Modem
After the camera's indicator turns green, you may set up the camera. Continue by following the procedure described
in the included Setup Guide.
• If the indicator does not turn green, see 1.2 Camera Indicator Issues in the Troubleshooting Guide on the included CD-ROM.
2
Rear View
*1
D
FACTORY DEFAULT
D
RESET button
E
Serial number label
F
Stand/Tripod Mounting
E
Hole
G
External INPUT
F
interface
H
DATA/POWER IN
G
H
™
turned off by default.) Refer to the operating instructions included with your router or to the Panasonic Network
LAN cable
(Cat-5 straight cable)
Power transfer unit
LAN cable
Router
Modem
Internet
3
2
1
LAN cable
(Cat-5 straight cable)
PC
BL-C121
Front View
A
B
C
AC adaptor
PC
To the power
outlet
(For BL-
C121CE/BL-
C121E use an
AC cord)
AC adaptor
Rear View
A
Indicator
*1
B
Lens
C
Microphone
D
E
F
3
Connect the AC adaptor to the power
transfer unit and plug the AC adaptor
into the power outlet.
• Confirm that the indicator turns
To the power
green after about 1 minute. If it does
outlet
not turn green, see 1.2 Camera
(For BL-
Indicator Issues in the
C101CE/
Troubleshooting Guide on the CD-
ROM.
BL-C101E
use an AC cord)
• When you operate the camera, the
power outlet should be near the
camera and easily accessible.
• Use only specified Panasonic AC
adaptor (Order No. PQLV206Y for
BL-C101A, PQLV216CE1Z for BL-
C101CE, BL-C101E).
• The camera may become warm.
This is normal.
1
Confirm that the WIRELESS/WIRED switch
on the side of the camera is set to WIRED.
2
Connect the LAN cable to the camera and
the router.
3
Connect the AC adaptor cord to the DC IN
jack.
4
Plug the AC adaptor into the power outlet.
• Confirm that the indicator turns green
after about 1 minute. If it does not turn
green, see 1.2 Camera Indicator Issues in
the Troubleshooting Guide on the CD-
ROM.
• When you operate the camera, the power
outlet should be near the camera and
easily accessible.
• Use only specified Panasonic AC adaptor
(Order No. PQLV206Y for BL-C121A,
PQLV216CE1Z for BL-C121CE, BL-
C121E).
• The camera may become warm. This is
normal.
D
FACTORY DEFAULT
RESET button
E
WIRELESS/WIRED
switch
G
F
LAN port
G
Serial number label
H
H
Stand/Tripod Mounting
I
Hole
I
External I/O interface
J
J
DC IN jack
K
K
Hook for AC adaptor
cord
™
feature is
Green
Green
